High-Precision Crisp Biscuit Production Line with Automated Dough Forming and Cutting

Product Description

High-Precision Crisp Biscuit Production Line with Automated Dough Forming and Cutting
Product Description
1. Equipment name: Crispy and tough multi-functional biscuit production line;
2. Equipment model: KD400;
3. Scope of application:
Cooperating with relevant processes, it can produce multiple categories of biscuit products:
Crispy biscuits such as: Oreo biscuits, black biscuits, tracker biscuits, monkey mushroom biscuits, caramel biscuits and other products;
4. Equipment production capacity: approximately 200-350 kg/hour depending on product type;
5. Equipment size: can be adjusted according to the size of the factory;
6. Total equipment power: about 510kw
1. Horizontal Dough Mixer
It is used for making dough.
After kneading, calendering and folding during the mixing process, a dough with smooth surface, good elasticity, toughness and extensibility is prepared. It is suitable for both tough biscuits and crisp biscuits.
It is a dual-purpose machine.
The high and low double belts can better meet the needs of cutting materials.
2. Biscuit Forming Machine
The roller printing machine is a special equipment for making crispy cakes.
After the dough is pre-rolled and broken by the roller printing feeder, it enters the roller printing cake mold for rolling and forming. The independent single control system can also be controlled in conjunction with the whole machine; the feeding roller There are grooves milled horizontally to make feeding more complete. The gap between the feeding roller and the cake mold is adjustable; the rubber rollers are adjustable on both sides, which can reduce the error in the weight of the cake base between rows. The cake mold and release glue The linear speed of the roller conveyor belt is consistent, reducing the deformation of the cake base.

3. Biscuit Forming Transition Conveyor
It is used to transfer formed biscuit to next process.
4. Oven mesh belt tension adjustment device & Oven head adjustment
5. Electricity Oven
The entire furnace is 24 meters long and divided into 3 temperature zones.
It is equipped with 2 sets of hot air fans and hot air circulation fans, 2 exhaust fans, 2 exhaust belt (air dampers), 2 observation ports, and the control panel has a temperature control and High temperature limit function; the furnace is equipped with a circulating fan. The hot air fan is installed at the top of each temperature zone and is separated from the furnace. The area where the product passes through the furnace is baked through hot air recirculation technology; each furnace section is A complete welded structure. Each section of the furnace has a duct system that disperses the air flow.
6.Out-oven machine and peeling device & Oil Sprayer
1.Peeling machine is used to connect the biscuits with other equipment after they are baked.
2.Oil Sprayer is used to spray oil on the upper and lower surfaces of biscuits, which can make the surface of biscuits shiny and moist, and taste more crispy and delicious. The oil spray machine adopts a centrifugal disc type and can spray oil on both sides of the biscuit at the same time. Equipped with oil mist collection system. The oil injection is uniform and the working environment is basically free of oil mist pollution. Equipped with a 4-meter oil filter, it can effectively reduce the impact of oil stains on subsequent transportation.

Detailed Photos
Product Parameters

Model	Capacity	Power	Layout
KD-400	200-350 KG/H	510 KW	70*5*3 m
KD-600	400-600 KG/H	850 KW	90*5*3 m

Packaging & Shipping
Company Profile
FAQ
End product display

---
