Mini Micro Small Slant Bed CNC Lathe Price

Product Description

High Precision Metal CNC Turning Center Slant Bed CNC Lathe
High Precision Metal CNC Turning Center Slant Bed CNC Lathe Application:
High Precision Metal CNC Turning Center Slant Bed CNC Lathe is mainly used for processing all kinds of shaft parts, disk parts, you can turn a variety of threads, arcs, cones and rotary body inside and outside the surface, to meet the ferrous metal and nonferrous metal high-speed cutting speed demand. Suitable for automotive, motorcycle, electronics, aerospace, military and other industries on the rotary parts for efficient, high-volume, high-precision processing. Processing accuracy can reach 7 level.
High Precision Metal CNC Turning Center Slant Bed CNC Lathe Features: 1.45 degree slant bed cnc lathe
2.High accuracy Taiwan linear guideways
3.Chip conveying capacity is large and convenient ,customer could choose chip conveying in the right or in the back
4.Spindle unit has two types ,the heavy duty cutting type and the high speed type.
5.The first one is suitable for bearing and gear processing .
6.The second type is suitable for high speed and jhigh precision processing.
7.Customers could choose any type of them
8.Screw pre-stretching structure
9.Gang type tool post
10.Optional turret
High Precision Metal CNC Turning Center Slant Bed CNC LatheTechnical Parameter :

Model	CK6432
Max.workpiece turning diameter on the machine	360mm
Max rotative diameter ofcarriage	150mm
Max processing length	450mm
Max travel of carriage Z/X	500mm/180mm
Form of spindle head	A2-6
Spindle go-bore dia	Ф48mm
Positioning accuracy	±0.02mm
Repeat Positioning accuracy	±0.01mm
Rapid feed on Axle X	6m/min
Rapid feed on Axle Z	8m/min
Max.Spindle speed	2000rpm
Taper of tail stock	Morse4#
Max travel of tail stock	80mm
Spindle motor power	4KW
Overall dimensions(L/W/H)	1870×1360×1520
Machine weight	1500kg

High Precision Metal CNC Turning Center Slant Bed CNC Lathe Details:
High Precision Metal CNC Turning Center Slant Bed CNC Lathe Real Picture In Woekshop:
Customer visit
High Precision Metal CNC Turning Center Slant Bed CNC Lathe For Delivery
Using standard export plywood package to delivery.
Any questions of the High Precision Metal CNC Turning Center Slant Bed CNC Lathe. Pls feel free to contact me: mobile +8613346326288

---
