US$1.20
1,000-9,999 Pieces
Basic Info.
Material Shape
Round Wire
Allowed Lateral Pressure
100(N/100mm)<1000(N/100mm)
Allowed Tensile Strength
<100N
Certification
RoHS, CE, ISO9001, VDE, CCC
Specification
2.0mm, 3.0mm
Production Capacity
500000 PCS/Month
Product Description
APPLICATIONS
CATV
Telecommunication networks
Active device termination
Metro
Local Area Networks (LANs)
Data processing networks
Test equipment
Premise installations
Wide Area Networks (WANs)
FEATURES
Low insertion loss and back reflection loss
Good exchangeability
Good Durability
High temperature stability
Standard: Telcordia GR-326-CORE
SPECIFICATIONS
| Single mode | Multimode |
| Insertion Loss | Typical≤0.2dB, Maximum≤0.3dB | ≤0.25dB |
| Return Loss | ≥50 dB (PC) ≥60 dB (APC) | ≥30 dB |
| Repeatability | ≤0.1 |
| Durability | ≤0.2 dB typical change, 1000 matings |
| Interchangeability | ≤0.2dB |
| Tensile strength | >70N |
| Operating Temperature | -40 to + 85°C |
ORDERING OPTIONS
| Connector Color | Boot (cable) Size | Boot Color | Fiber Type | Cable number | Application | Length |
| Beige | 0.9mm | Beige | 9/125μm (SM) | Simplex | PC | Customized |
| Blue | 2.0mm | Black | 50/125μm(MM) | Duplex | APC | |
| Green | 3.0mm | Blue | 62.5/125μm(MM) | Fan-out (4f) | | |
| | Green | | Fan-out (6f) | | |
| | Gray | | Fan-out (8f) | | |
| | Red | | Fan-out (12f) | | |
| | White | | Fan-out (24f) | | |
FAQ:
1.What is our Promise?
KOC is committed to providing the world's high quality Fiber Optic Communications Products at a competitive price while maintaining world-class service to all our customers.
2.What is our Service?
Every KOC employee is dedicated to providing service that goes beyond the norm.
From doing special searches of hard to find items to the everyday tasks like answering the phones;we do it better,nicer,faster,all for your convenience and confidence in KOC.
3.What is KOC's Quality Control?
At KOC,our standards are high,and this is reflected in the products material we carry from the most respected manufacturers in the world.
>>
