| US$5,000.00-10,000.00 | 1 Piece (MOQ) |
| PARAMETERS | MQ-6025A | |
| Swing dia.of workpiece | 250mm | |
| Distance between centers | 700mm | |
| size of working area | 940*135mm | |
| Longitudinal travel of table | 480mm | |
| Swing angle of table | 120°(60°) | |
| Max travel of wheel head cross vertical | 225mm | |
| Wheel center line of the min distance between the top | 50mm | |
| Wheel center line of the max distance between the top | 265mm | |
| The max movement in the vertical direction | 270mm | |
| Wheel center line up to the top | 200mm | |
| Wheel center line down to the top | 65mm | |
| Swing angle of wheel head in horizontal pline | 360° | |
| Swing angle of wheel head in vertical pline | 30°(±15°) | |
| The end taper of the spindle | MT3# TAPER ANGLE | |
| Grinding head motor power 50Hz | Power | 0.85/1.1KW |
| Speed | 1400/2800rpm | |
| The speed of grinding head | 3010/6010rpm | |
| The Motor of Cylindrical grinding attachment:50Hz | Power | 0.25KW |
| Speed | 1400RPM | |
| The size of the machine | 1650*1150*1500mm | |
| The weight of the machine | 940kg | |
| Contact Us: |
| Ashley Liu TENGZHOU HOTON MACHINERY CO.,LTD MP/Wechat:0086 18266002891 ashley@hotonmachinery.com |
| Company Profile: |
| Tengzhou Hoton Machinery Co.,LTD was established in 2006, and is the professional machine manufacturer in China. There are 480 workers, of whom 60 are engineers. It has an area of 46,000 square meter, general assets 30,000,000. It has a store of 350 equipments and the good ability of products design & manufacturing. It has export quality permit from 2007, and has export right given by the State Foreign Economic Trade Committee in 2008. |
| The leading products: "Hoton" series of CNC machines, Lathes, Milling machines, Drilling machines,Grinding machines, Saws, Sheet metal machines, Metal forming machines, and other machine accessories.Some products have national patent.It has fourteen series, over eighty models by itself. It has the ability of making 100,000 sets every year. All the products are designed perfectly and has high quality high performance and low price, and the excellent quality guarantee system. The products have past ISO9001 and CE certification since 2009. The products have been export to five continents, over forty countries and areas. It resulted to the attraction of client abroad and home, the quickly promotion of products sale. |
| Tengzhou Hoton Machinery Co.,Ltd. is willing to make common progress and developments with all the customers. Quality first,Constantly perfecting skills. |
