Product Description
Product Description
1.Parameters:
| ZX-247II
| Zx-256II
|
Max. paper size
| 470*365mm
| 560*400mm
|
Max. printing area
| 454*345mm
| 540*395mm
|
Min.paper size
| 80*120mm
| 90*140mm
|
Paper weight
| 28~260g/sqm
| 28~260g/sqm
|
Printing speed
| 2000~9000 sheets/hour
| 2000~9000sheets/hour
|
Plate size
| 380*470*0.13mm
| 420*560*0.15mm
|
Blanket size
| 415*470*1.68mm
| 560*455*1.95mm
|
Ink roller
| 14 pieces (3 ink form rollers)
| 14 pieces(3 ink form rollers)
|
water roll
| 5 Pcs Rollers (2 form)
| 5 Pcs Rollers (2 form)
|
Power of primary motor
| 1.5kw
| 1.5kw
|
Power of air-pump motor
| 0.55kw
| 0.55kw
|
Power supply
| 220V/50Hz
| 220V/50Hz
|
Dimension
| 2910*1000*1400mm
| 2910*1100*1400mm
|
Net weight (approx.)
| 1700kgs
| 1860kgs
|
2.Description:
1) Capability: Inking device of each unite has, guarantee the high precise printing quality, and can print double color, which can improve the efficiency and reduce the cost.
Advanced ink feeding system, consisting of 14 ink form rollers including 3 ink rollers, ensure top quality prints
2) Easily operate: water supplying, ink supplying and platform pressing each unites can be finished at different lever with the same handle. Joint pressure of printing rollers is controlled with an electric eye, which is more reliable and easy to be regulated.
3) Accurate orientation: adopt front lay and double-side pull guide for orientations, also install with tune-up devices for feed table, its side lay, plate cylinder, and No.2 unit.
4) Adopt independent ink system and damping system, can freely adjust feeding, best meeting various demands of different printing matters, more suitable for color printings.
5) Presetting counter: automatically stop feeding paper once preset quantity task are completed.
6) Double detect device: detect double sheets and multiple sheets, and automatically eliminate double and multiple sheets.
Double turn-around function: ensure the sufficient dryness of ink demanding of special printing matter.
7) Sprayer device: make spraying and printing run in synchronization, prevent printing matter from dirty
8) Centralized oil feed system: more convenient for maintenance
9) Touch device: realize rapid loading and unloading plate, easier operation and better safety.
3.Company strength:
1.15 years factory experience
2.10 years export experience
3.Over one hundred professional factory workers
4.100% quality guarantee,supply all kinds of certificates
5.Good after-sales serive,we send engineers to repair machine overseas.
6.Primary products:
Automatic High Speed Flute Laminater
ZXSCM Book Case Making Machine
650UV Coating Machine
ZX-650C Manual Paper Pasting Machine
Box Making Machine
Hot Melt Gluing Machine and Gluing Machine
Table Gluing Machine
Paper Pressing Machine.etc
7.Following is our factory pictures:
4.Certificate:
5.Trade show:
6.Packaging & Loading:
Welcome to visit our factory!
>>
