Large Heavy Bed-type Universal Milling Machine with Swivel Head X716

US$25,000.00-32,000.00 1 set (MOQ)

Basic Info.

Model NO.

X716

Structure

Bed type

Milling Cutter Type

Vertical Milling Cutter

Milling Cutter Structure

Indexable Type

Controlling Mode

Artificial

Automatic Grade

Semiautomatic

Precision

Certification

CE, ISO 9001

Condition

New

Worktable size

2500X600

X-axis travel

1800mm

Y-axis travel

700mm

T-slot

5/20/100

Spindle bore taper

ISO50

Net weight of machine

9000kg

Transport Package

Wooden Cases

Specification

11 kW

Trademark

Dalian ZT Machinery

Origin

China

HS Code

84595900

Production Capacity

200 Sets/Year

Product Description

Main Feature
all guides are hardened, ground and supplied with oil by a central lubrication unit. Universal swivel head swings easily to a horizontal position. Servo-motor on all axes, infinitely variable feed, rapid feed, and speed control. Electronic hand-wheels on all axes. Ball screw drive on all axes Powerful main motor. Technical specifications:

Specifications	Unit	X716
Spindle hole taper	mm	7:24 ISO50
Spindle speed range	r/min	Variable 6-300,30-1500
Distance between spindle axis and column guideway	mm	8-660
Distance between spindle nose and table surface(V)	mm	0-700
Distance between spindle axis and table surface(H)	mm	8-660
Table size	mm	2500*600
T slots	mm	5/20/100
Table travel-X	mm	1800(2000)
Table travel-Y	mm	700
Table feed-X/Y	mm/min	2.5-3000
Table feed-Z	mm/min	2.5-2500
Table rapid feed X/Y/Z	mm/min	6000/6000/3000
Main motor power	Kw	11
Torque of X/Y/Z axis AC servo motor	Nm	18/23/18
Cooling pump motor power	w	90
Overall size	mm	438025202800
Weight	kg	9000

Standard accessories:

NO.	Name	Specificcations	Q'ty.
1	Milling machine	X716	1
2	Draw bar		1
3	IS050 taper shell end mill holder	ISO50-Φ40	1
4	7: 24 middle cover	7: 24 IS050/MS4	1
6	Oil gun		1
6	Foundation bolt	M16×450	6
7	Allen wrench	5,8,10	1
8	Double-ended wrench	27×30	1
9	Double-ended wrench	36×41	1
