Multi Function Automatic Small Rewinding Slitting Machine Use for Paper and Labels

Product Description

Multi Function Automatic Small Rewinding Slitting Machine Use for Paper and Labels Main technical parameters

Model	DG400
Max Unwinding Diameter	φ600mm
Max Rewinding Diameter	φ600mm
Max machinery speed	300m/min
Max Material Width	400MM
Max slitting width	30MM
Unwinding Paper core diameter	3"
Main motor Power	1.5kw
Rewinding motor Power	1.5kw
Powder Brake	5kg
Machine Total Power	5kw
Suitable Material	Plastic Film ,and laminated film 12-180um,PE,PVC about 40um-150um
Machine color	White Milk (also can according customer choice )

Description of main parts
Unwinding Parts
Air shaft unwinding
Horizontal EPC
Auto tension control
Traction transmission part
When ac motor driving
Low synchronous belt transmission
Low rotating body adopts imported bearings
Double roll to roll, soft and hard combine
Rewinding Part
Air shaft rewinding
Auto tension control
Main Parts List
PLC Siemens,Germany
Frequency Inverter Innovance Shenzhen
Main Machine Taiwan Weinview
EPC Guangzhou
Powder Brake Ningxia
Main Motor Siemens
Rewinding Motr Siemens
Main Pneumatic Component Taiwan Airtac
Main Bearing NSK Japan
Low voltage electrical China delixi
Others
Random accessories A set of tools
A set of other random accessories
Pre-sales issues 01. How to get in touch with us? Call us directly
Direct to the company: National Road 104, Songqiao Industrial Zone, Wanquan Town, Pingyang County, Zhejiang Province, China 02. How to answer technical guidance? For some customers who need non-standard equipment, we will communicate with the company's relevant technical personnel according to the customer's specific requirements, taking into account the technical feasibility and production costs, and give customers solutions. 03. How to recommend products? We have nearly 14 products in four series. We can also provide non-standard equipment production and new product development services according to customer requirements. According to the customer's requirements to be produced, the purpose of the product to be purchased, the environment, the purchase volume and other related conditions, we will recommend several cost-effective products for the customer to choose. 04. How to make a quotation? Based on our company's research and development costs, production costs and customer purchases, we conduct calculations to determine the price of the product.
Problems in sale 01. About payment After signing the contract, 30% of the total payment will be paid in advance, and the factory will accept the payment and pay the full amount of the machine for delivery. 02. About delivery time About 45 working days after receiving the deposit (non-standard machine), the factory will re-decide whether to change the delivery date when the order is confirmed. The standard machine is generally within 30 working days after receiving the deposit 03. Order tracking After the customer places an order, our company will send professional personnel to track the order and regularly report the production progress to the customer. Customers can check the order status on the official website (delivery query). 04. Product testing During the production process, our company will adopt strict inspection process to ensure product quality. Through internal inspection, we ensure that the components produced by our company meet the technical requirements; through external inspection, we ensure that the components produced by our company are not subject to quality problems; and then pass the whole machine inspection to ensure that the mechanical equipment meets the technical production requirements . 05. Product packaging Before the product is shipped, it will be packed in a strict vacuum plus bottom tray (wooden tray or steel tray) 06. Product Transportation Products are generally shipped from Ningbo Port, China to the destination port by sea.
After sales question 01. Shelf life/warranty period of the product The product warranty period is generally one year, and our company provides lifetime maintenance services. If the machine has quality problems, our company will help the customer to solve it through the following ways: a. Send spare parts to the customer. b. Remotely assist customers in maintenance. c. Notify our agent company to send personnel to the customer's factory for maintenance. d. Our company directly dispatches relevant personnel to the customer's factory for maintenance. 02. About transportation damage In the process of product transportation, if product damage occurs, it is determined that our product packaging and reinforcement work is not in place, and our company will bear the corresponding losses. 03. About machine maintenance We will contact customers on a regular basis on how to maintain and maintain the machine. For domestic customers, we will have a master to provide on-site service. 04. Problems during use If there is any problem in the process of using the product, the customer can directly call or send an email to our after-sales department (24-hour hotline). The personnel of our department will respond immediately and make a decision on the response measures within 24 hours.

---
