Kraft Machine, Fluting Corrugated Duplex Board Cardboard Making Machinery Testliner Paper Paperboard Machine

Product Description

Fluting Paper/Kraft Paper/Corrugated Paper/Cardboard Paper Making Machine Paper making machine Technical requirementPaper and pulp ratioPaper type: fluting and test liner paperPaper weight: 85-100g / m2Proportion of pulp: determined and adjusted by the user according to the productPaper machine specificationsOutput: 120t / 24hDesign width:Wire width (nominal): 2950mmPaper roll width: 2560mmFinished paper width: 2500mmGauge: 3600mm (subject to final design)Various speed:Designed speed: 400 m / minBalance speed: 450 m / minTransmission speed: 400 m / minRolling roller balancing speed: 1200m / minWorking speed: 300-400 m / minDryness:Out of wire section: 20-22% (± 1%)After press section: 44-46% (± 1%)Before sizing: 92%Paper roll machine: 92%Arrangement of the paper machine: Stand at the roll machine and look at the wire section, the drive is on the left (right) hand side.Paper machine layout form: Single layer layoutPaper Making Machine Raw materialUse Wheat Straw pulp, Rice Straw, Waste Books Paper, Wood Chips, Waste Paper, Bagasse, Wood pulp board, waste paper to produce Kraft paper, test liner paper, corrugated paper, fluting paper, cardboard paper.
Why choose us?
(1) professional engineer team with 30 years experience;
(2) we can supply turn-key solution without any trouble;
(3) we have strict quality control system and ensure there is no unqualified product;
(4) professional installation technician and clear technical training for your workers;
(5) strict recalling system: if any problem of Paper Making Machine, we will recall it and change a new one for free;
Paper Making Machine Main Equipment Pulp Making Equipments
High contentration hydrapulper, Vibrating screen, Pressure Screen,Double disc pulp refiner, Pulp pump, Low concertration cleaner,Impeller, High concentration cleaner, High speed washer, Decker thickener, Fiber separator, Rejector separator
Paper Making Equipments
Headbox, Cylinder mold, Cylinder vat, Touch roll, Press roll, Leading roll, Dryer, Sizing machine, Calender machine, Winding machine, Rewinder, Foundation frame

No.	Item	Function
Pulp making section
1	D type Hydra-pulper	To break the waste paper into pulp and drop down the impurity and pins
2	High density pulp cleaner	To separate and sieve the small stone,staples,heavy impurity in the pulp
3	Fiber separator	To beating pulp again and separate long and short fiber
4	Vibrating screen	To separate and remove the small impurity(such as broken plastic tape,foam,etc)
5	Pulp refiner	To grind pulp fiber
6	Low concentration pulp cleaner	To remove the sand and tiny impurity in the water and pulp
7	Pressure screen	To screening pulp fiber
8	Impeller	To stir the pulp and make sure the pulp and water mixed well
9	Pulp pump	To provide the pulp for the needed machine
Paper making section
10	Cylinder mold part	To forming wet paper web
11	Vacuum dewatering part	To absorb the water in the wet paper
12	Press part	To dewatering by mechanical gravity press force
13	Dryer section part	To dry wet paper
14	Sizing press part	To glue paper surface to improve paper quality strength and stop printing ink spreading
15	Dryer section part	To dry paper after gluing wet
16	Calendering part	To glazing paper surface,control paper thickness,tightness
17	Winding part	To reeling output paper be a jumbo paper roll
18	Paper rewinding part	To rewind the jumbo roll paper to different size (width&diameter) according to your requirement
Boiler section
19	Gas/diesel/coal boiler	To provide high temperature and pressure steam to dryer to dry paper

Details of Paper Making Machine Description: Kraft and Corrugated Paper Making Machine is a production line that use waste books paper, wood pulp board, waste paper box, old corrugated carton, wheat straw pulp, wood etc. to produce Kraft paper,test liner paper, corrugated paper, fluting paper, cardboard paper. Kraft and corrugated Paper Making Machine Is Mainly Used as The Package Material, High Strength, Brown Color. Full Bleached or The Half Bleached Kraf Paper Pulp Is Light Brown Color , Cream Color, or The White Color. Most Are Jumbo Rolls, Some Are Sheets. The Kraft Paper Is Generally Made Into The Cement Paper Bags, Envolope, and Cables Protective Paper. Good Quality Waste Carton Recycle Corrugated Paper Making Machine.
Company Profile Since 1989 Qinyang City Haiyang Papermaking Machinery Co., Ltd has been established who is specialist in manufacturing a wide range of Paper Making Machine for Kraft, Test liner, Fluting paper, Corrugate, Writing & Printing, Newspaper, Duplex Board. We have more than 30 years expertise lies in applying state of the art technology to provide cost effective custom designed solutions to suit their varied requirements. The main series of the products are tissue paper machine; kraft paper/testliner /fluting paper machine;writing paper machine and special paper machine,etc. This company provides customers high efficiency and practical paper making production line with low carbon environmental protection thought. At present, our products have been sold to more than twenty provinces, cities and autonomous regions in domestic region and exported to Vietnam,Egypt, Bangladesh,Malaysia,Pakistan,Iran and other countries. Certificate Our service Pre-sale Service --24 hours phone, email, trade manager online services; --We will supply the detailed project report, detailed general drawing, detailed flow process design, detailed layout factory drawing for you until meet your requirement; --we welcome you to come to our paper making machine factory and paper mill factory to have a look and check; --We will tell you all the necessary cost when set up a paper mill factory; --We will answer you all the questions within 24 hours; --We will send you various quality paper samples made by our Paper Making Machine for free; --We can supply turn key-project service. On-purchase Service --We will accompany you to check all the equipment made by us, and help you to make the plan of installation; --We will supply paper machine assembly drawing, the foundation and foundation load diagram, transmission diagram, formal installation drawing, use and installation instructions and a full set of technical data after signing the contract. After-sales Service --We will delivery the machine as soon as possible according to your requirement, within 50 days; --We will send rich practiced experience engineers to you to install and test the machine and train your worker for free; --We will give you one year guarantee time after the machine can run well; --After one year, we can guide and help you to maintain the machines; --Every 2 years, we can help to overhaul the complete machines for free; --We will send you spare part in lower price. This is Summer, manufacturer of Paper Making Machine with turn key service.We mainly produce all kinds of paper making machine. Please send inquiry to get more details.

---
