| US$399.00-699.00 | 1 Piece (MOQ) |
| Optical System | Common optical system |
| View Head | Articulated Free Trinocular Head. Inclined at 30°,360° Rotatable.(Interpupillary Distance:55-75mm) |
| Eyepiece | PL 10x/23mm high eyepoint eyepiece,diopter adjustment ±5.tubeφ30mm |
| Objective | Plan achromaic objectives 4X,10X,40X,100X |
| Nosepiece | Backward quardruple objective nosepiece |
| Condenser | Abbe Condenser set |
| Stage | X-axis low hand position double Layers Mechanical Stage (steel wire transmission) Stage Size:220x148mm Moving Range:76x50mm Precision:0.1mm Damped double slide clamp |
| Focusing | Coaxial Coarse & Fine Focus knobs Precision:0.002mm |
| Illumination | 3W LED lamp with Kohler illumination system |
| LCD | 8''color LCD Pixels:976(H)x582(v) Color System:PAL/NTSC4.43/NTSC3.58/SECAM |
| Optional Accessory: | |
| Optical System | Infinity achromatic correction optical system |
| Nosepiece | Backward quintuple objective nosepiece |
| Objective | 1.Achromatic objectives:40x,10x,20x,40x,60x,100x 2.Plan objectives:20x,60X 3.InfinityPlan Achromatic objectives:4X,10X,20x,40x,60X,100x |
| Phase Contrast Accessory | 1.Dial phase contrast apparatus 2.Insert phase contrast apparatus |
| Dark Filed Condenser | 1.Dry darkfiled condenser 2.Oil-darkfiled condenser |
| Illumination | 5W LED |
