| Processor | CPU | Intel Jasper Lake N5105 (2.0GHz-2.09GHz, 10W ) N5100 (1.1GHz-2.8GHz, 6W ) N5095 (1.1GHz-2.8GHz, 15W ) optional (N6000/N6005/N4500/N4505/) |
| BIOS | AMl EFI BIOS | |
| Chipset | SOC | |
| Memory | Type | LPDDR4X |
| Socket | Onboard 8GB | |
| Max Size | 16GB | |
| Storage | SATA III | 1*SATAIII 6Gb/s SSD/HDD(7 thickness), |
| M.2 SSD PCIE | M.2 2280 SATA NGFF (Nvme OEM ) Max 2TB | |
| Graphics | GPU | Intel® UHD Graphics |
| HD | 2 x HD | |
| VGA | 1 x VGA | |
| Network | Controller #1 | Built-in LAN chip, |
| Interface | 1 x RJ45 | |
| wifi / BT | intel 7265/ 3165/ RTL8821CE Dual band WIFI support 2.4GB/5.0GB + BT4.2 | |
| Antenna1 FPC WiFi 2.4+BT x1 | ||
| Antenna1 FPC WiFi 5.0 | ||
| I/O | USB | 2 x USB 3.0, 2 x USB 2.0 |
| Display Interface | 2 x HDMI, 1*VGA | |
| LAN | 1xRJ45 (100/1000 Gigabit Lan) | |
| Audio | 1 x 3.5mm Audio Jack (MIC&Speaker 2 in 1 combo) | |
| DC | 1*5.5/2.1mm DC Jack | |
| Power Key | 1*Power on/off button | |
| LED Indicators | Blue light - Swith on | |
| JAHC Tech | Real-time clock,timing boot | Supported |
| Auto Power On | Supported | |
| Wake On Lan | Supported | |
| TPM 2.0 | CPU interation | |
| Operation System | Win | Win10 Home/Win10 pro/Win11 Home/Win11 pro/Win11 IOT/ Ubuntu |
| Linux | Supported | |
| Power | Power Type | DC-In |
| Power Adapter | 12V/2.5A AC adapter(∮5.5mm power connector) | |
| Mechanical | Dimensions (W x D x H) | 12.8*12.8*4.5cm weight:345g |
| Color box | 22.2*15.2*7cm weight:900g | |
| Carton | 43.5*34*31.5cm 20pcs/carton, 18.5kg/CTN, 0.046CBM/CTN, | |
| Fan | Built in intelligent Fan | |
| Material | ABS | |
| Mounting(Optional) | Vesa Bracket and screws | |
| Color | Iron Grey or ( Balck for OEM ) | |
| Environment | Working Enviroment Temp | 0~40ºC |
| Stock Enviroment Temp | -20~40ºC | |
| Relative Humidity | 90% @ 40 °C |
