| US$33.00 | 1 Piece (MOQ) |
| Specification Appearance Details | ||||||
| Type | Details | Description | ||||
| Product Dimension | 170X101MM | |||||
| Packing measurement | 134*119*198mm | |||||
| Product gross weight | 0.65kg | |||||
| product weight | 0.43kg | |||||
| Net weight | 19KG | |||||
| Gross Weight | 20KG | |||||
| Packing box | 61.5X40.4X41.5CM/30PCS | |||||
| Power | 47W | |||||
| System & Hardware Details | ||||||
| Type | Details | Description | ||||
Display Parameter | Display Technical | LCD | ||||
| Light Source | LED | |||||
| Color temperature | 4800K | |||||
| Light Source Life | 30000H | |||||
| Light Luminance | 130 ANSI | |||||
| Light Type | LED | |||||
| Standard Resolution | 1920*1080/60HZ | |||||
| Support resolution | 1080*1920/60HZ | |||||
| contrast ratio | 1500:1 | |||||
| Projection Area | 30-120 inch | |||||
| Picture scale | 4:3/ 16:9 | |||||
| Optimum size | 60-90 inch | |||||
| Contrast | 0.9 : 1 | |||||
| Luminance Uniformity | 75% | |||||
| Projection Distance | 1-2.5M | |||||
| Focus mode | Manual Focus | |||||
| Keystone Correction | Automatic up and down trapezoid | |||||
| Projection Mode | Hoisting/Front/ Rear Project | |||||
| Speaker | Built-in Box Speaker 4Ω3W*1 | |||||
| Connector Details | ||||||
| USB USB Port | USB USB Port | Standard USB2.0 | ||||
| HDMI HDMI Port | HDMI HDMI Port | Standard HDMI2.0*1 | ||||
Audio Output Port | φ3.5 φ3.5 Audio Port | Standard φ3.5 Audio Port *1 | ||||
Power Jack | AC AC Port | 100~250V 50/60HZ | ||||
Power Button | Turn on/ off Button | Power Key *1 | ||||
| Standard Accessories | ||||||
| Power Cable | Standard | AC,1.2M AC Cable *1 | ||||
| HDMI HDMI Cable | Standard | |||||
Remote Control | Standard | Remote *1 | ||||
| Software Details | ||||||
| Type | Details | Description | ||||
Operation System | CPU | amlogic 950s | ||||
| • Cortex-A53 L2 cache • NEON SIMD co-processor | ||||||
| GPU | • ARMv8-A architecture with Neon extensions | |||||
| (GP)(PP)multi-core GPU processor handles all OpenGL ES 2.0 graphics programs | ||||||
| • 2.5D • CoreSight debugger support | ||||||
| Dislapy | • Dual-channel LVDS output supporting up to 1920*1080P 60Hz | |||||
| multimedia | • MVC,MPEG1/2/4,VC-1/WMV,AVS+,RealVideo, MJPEG,H.264,VP9,H265-10JPEG. | |||||
| • AVE-10 is capable of decoding 4K2K | ||||||
| Amlogic Video Engine (AVE) with dedicated hardware decoder | ||||||
| system version | Android 13 | |||||
| Memory/Storage | 2 + 8 | |||||
| WiFi network support | 802.11 /b/g/n+BT4.2 2.4G+5G Dual WiFi Modes | |||||
| Display Color | Customizable modes | |||||
