Hualong Machinery 3axis CNC Waterjet Cutting Machine Water Jet Saw Jogj Pressure Waterjet Pump

Product Description

3-Axis CNC Waterjet Cutting Machine
Model: HLRC-3020 Using a remarkably high-pressure jet of water and abrasive (typically garnet) to erode a precise and narrow line in the stock material, this industrial powerhouse is capable of cutting almost any material while upholding unparalleled precision.
This advanced 5-axis waterjet cutter effortlessly slices through any angle within a +60° range, overcoming traditional water cutting inclinations and achieving seamless 2D/3D cutting. Its line cutting precision is +0.1mm, while angle cutting accuracy is +0.1°.
Our superior machine adeptly handles bevel, straight, conical, circular, rotating, groove, chamfer, and arbitrary surfaces with ease. It slices through a myriad of materials including steel, stainless steel, aluminum, titanium, marble, granite, ceramic, glass, rubber, foam, and more.Key Features:1) Capable of processing any curve cuts with unmatched flexibility, convenience, and versatility.
2) Delivers fast, smooth notches with no dust, no thermal deformation, and zero pollution. Its minimal cutting force ensures stress-free processed parts. 3) The water jet stream's narrow kerf, typically about 0.5-1.0 mm wide, optimizes material usage and enhances cost efficiency.
4) Cut Recovery - Seamlessly resume from where the Jet stopped.
5) Programmable Z-axis height, retracts seamlessly between pierces.
6) Equipped with a servo motor, linear sledge, vehicles, helical rack, and pinions for swift, smooth axial movement.
7) High-Performance drive system ensures the highest precision in parts production along with maximized processing speed.
8) Driver system sealed against water, dust, and grit for extended longevity.

Technical Data for water jet cutting machine
Model No.		HLRC-3020	HLRC-4020
Working area	mm	3300*2100	4100*2100
X-axis stroke	mm	3200	4000
Y-axis stroke	mm	2000	2000
Z-axis stroke	mm	80-130	80-130
Max. angle of C axis rotation	°	+/- 360	+/- 360
Max. angle of A axis swing	°	+/- 60	+/- 60
Cutting accuracy	mm	+/- 0.1	+/- 0.1
Repeatable accuracy	mm	+/- 0.05	+/- 0.05
Traverse speed	mm/min	5000/15000	5000/15000
Main motor power	kw	37	37
Dimension (L x W x H)	mm	443x278x220	494x280x222

Included Accessories:Applications:* Stone/Ceramic industries: Ideal for countertops, art puzzles, flooring inlays, and mosaics.
* Glass industry: Perfect for bathroom glass, shop window glass, automotive glass, and appliance glass.
* Metal industries: Exceptional for stainless steel, metal decoration, equipment covers, and metal part cutting.
* Gasket Cutting
* Foam Product CuttingDetailed Images:Water Jet Software SolutionBrand: Weihong
Origin: China
Sophisticated motion control solutions to address high-pressure water jet taper, towing, and other technical challenges, ultimately achieving flawless dynamic five-axis cutting.
User-friendly and simple to master. Primary MotorManufactured by: Siemens
Origin: China
Power Output: 37 kW
Efficiency Rate: 92.7%
Generates motion energy through electrical energy for the high-pressure pump. Intensifier UnitConsistently produces high-pressure water.
Key components sourced from Ashcroft, USA for stable performance and operation. Servo Motor UnitBrand: Weihong
Origin: China
Number of Revolutions: 0-1500 RPM
Ensures precise and smooth movement along the X-axis. Advanced Laser SensorBrand: Weihong
Origin: China
Automatic scanning precision altimeter function, maintaining a constant distance between the knife head and the workpiece surface. State-of-the-Art Factory WorkshopHigh-Quality Fabrication Equipment* Engineered with over 30 years of expertise and patented technology.
* Extensive range of machines readily available for order.
* Highly experienced technicians ready to address all your inquiries.
* Customization options available to meet your unique requirements.

---
