The EPDM lined lay-flat hose is single jacket made of high tenacity polyester filament / spun polyester twill or plain weave and liner is EPDM.
Acid and alkali resistance,Chemical resistance,oil resistance,abrasion resistance,low maintenance.
Standard Length: 15M(50feet), 20M(66feet), 25M (82feet), 30M(100feet).
Temperature Range: -40°F to 158°F(-40°C to 70°C), other temperature on request.
Color:White, Red, Yellow or other colors on your request.
| Inner diameter | Working pressure | Bursting pressure |
| inch | mm | Psi/Bar | Psi/Bar |
| 1" | 25 | 190/13, 232/16, 300/21,400/28,etc | 570/39, 700/48, 900/63,1200/84,etc |
| 1 1/2" | 38 | 190/13, 232/16, 300/21,400/28,etc | 570/39, 700/48, 900/63,1200/84,etc |
| 1 3/4" | 45 | 190/13, 232/16, 300/21,400/28,etc | 570/39, 700/48, 900/63,1200/84,etc |
| 2" | 50 | 190/13, 232/16, 300/21,400/28,etc | 570/39, 700/48, 900/63,1200/84,etc |
| 2 1/2" | 65 | 190/13, 232/16, 300/21,400/28,etc | 570/39, 700/48, 900/63,1200/84,etc |
| 3" | 80 | 190/13, 232/16, 300/21,400/28,etc | 570/39, 700/48, 900/63,1200/84,etc |
| 4" | 102 | 190/13, 232/16, 300/21,400/28,etc | 570/39, 700/48, 900/63,1200/84,etc |
- Jacket: 100% high tenacity polyester woven reinforcement.
- Lining: Rubber(we can also provide the PVC and TPU and EPDM lining.)
