Denp Jaw Plate / Crusher Part / Crusher Plate

Product Description

Jaw crusher can reach the crushing ratio of 4-6 and the shape of final product is even. It is widely applied to crush high hardness, mid hardness and soft rocks and ores such as slag, construction materials, marble, etc. The pressure resistance strength is under 200Mpa, that is, suitable for primary crush. Jaw crusher can be used in mining, metallurgical industry, construction, road and railway building, conversancy, chemistry, etc.

Features:
1. simple structure, easy maintenance;
2. stable performance;
even final particles and high crushing ratio.

Model	Feed Opening Size	Max Feed Size	Capacity	Motor Power	Adjustment Range of Discharge Opening(mm)	Eccentric Shaft Speed	Weight (t)
	(mm)	(mm)	(m³/h)	(kw)		(r/min)
PEX100× 600	100× 600	80	2-8	7.5	7-21	330	1
PEX150× 750	150× 750	120	5-16	15	18-48	320	3.5
PEX250× 750	250× 750	210	8-22	22	25-60	330	4.9
PEX250× 1000	250× 1000	210	10-32	30	25-60	330	6.5
PEX250× 1200	250× 1200	210	13-42	37	25-60	330	7.7
PEX350× 700	350× 700	300	16-35	30	30-80	300	6.5
PEX300× 1300	300× 1300	250	15-55	75	30-80	300	11
PE150× 250	150× 250	125	0.6-3	5.5	10-40	300	1
PE250× 400	250× 400	210	3-13	15	20-60	300	2.8
PE400× 600	400× 600	340	10-34	30	40-100	275	6.5
PE500× 750	500× 750	425	20-52	55	50-100	275	10.5
PE600× 900	600× 900	500	30-75	55	65-160	250	15.5
PE750× 1060	750× 1060	630	72-130	110	80-160	250	28
PE870× 1060	870× 1060	670	160-210	110	200-260	250	30.5
PE900× 1200	900× 1200	750	90-190	132-160	95-180	200	50
PE1000× 1200	1000× 1200	850	197-214	132-160	230-265	200	51
PE1200× 1500	1200× 1500	950	188-500	160-250	150-350	180	100.9
PE1400×1800	1400×1800	1100	288-480	250-315	500-1100	180	120

---
