Styrofoam Hot Wire Cutting Foam Machine 2D 3D EPS Foam Cutter

Product Description

Product Description
This machine is suitable for producing PET plastic containers and bottles in all shapes. sponge/foam, spray-bonded cotton, latex/emulsion, artificial leather, in peculiar shape without burrs on the edges.Windows operating system, CAD software. It can diagnosis automatically, and give an alarm when the blade broken.
Features of automatic plate cutting machine :
1.Special equipment for external wall insulation board.
2.lt is suitable forblock cutting of the overall plate of the outer wall, with high cutting ef-ficiency, extremely small size error, and the diagonal can be controlled atone millimeter.
3.The machine adopts double frequency conversion speed regula-tion, which is stable in operation and has a wide range of speed regulation.
4.The stepless speed regulation is between 0-4m/min, which is suitable for therequirements of slow cutting and fast pushing.
5.Adopt large-capacitymulti-head double-stage transformer, wide temperature adjustment range,convenient heating adjustment, and smooth and flat cutting marks of electricheating wire.
Detailed Photos

Product Parameters

Product name	CNC plate cutter
Model	QJN-6008
Mainly Function	External wall insulation board cutting
Machine structure	Thick steel welded
Max. processing length	6000mm(Can be customized)
Max. processing width	1250mm(Can be customized)
Heating power	10KW
Voltage	220V/380V-50HZ
Cutting accuracy	±0.1mm
Number of heating wire	50 PCS
Cutting speed	0~2.5 m/min
