Corrugated Cardboard Preheater for 3 Ply Corrrugated Cardboard Production Line

Product Description

Corrugated Cardboard Preheater for 3 ply corrrugated cardboard production line
RG-1-900 top(core)paper preheater
structural features:
★preheat roller accord the pressure container national standards,and enclose the pressure container certificates and inspection certificate.
★Each roller surface after grinding precision grinding and dealing with hard chrome plating, Surface friction is small, durable.
★electromotion adjustment angle, and angle can rotation adjustment the preheat area in the range of 360°
technical parameters: 1.Effective width:1800mm
2,diameter of preheat roller:¢900mm 3,angle adjustment range:360°rotation
4,angle shaft diameter:¢110mm×2
5,steam temperature:150-180ºC
6,steam pressure:0.8-1.3Mpa
7,equipment size:Lmx3.3*Wmx1.1*Hmx1.3
8,single weight:MAX2000Kg
9,working power:380V 50Hz
10,Motor power:250W short(S2)working system

---
