Product Details
Product Description
Product Description
Product Description
MBP series cone crusher is equipped with a cone crusher suitable for medium and fine crushing with excellent performance, special crushing wall and concave design, supplemented by curved cavity and hydraulic cavity cleaning system, which can effectively improve crushing efficiency and effectively reduce operation loss.
PRODUCT PARAMETERS
Project
| Device Name
| Models and Specifications
| Power (kW)
| Amount
|
|
HP300 cone crusher
+
1542 return screen
| cone crusher
| equipment
| HP300
| /
| 1
|
triangle belt
| Standard
| /
| 7
|
motor
| Standard
| 250
| 1
|
return screen
| equipment
| 1542
| /
| 1
|
vibration motor
| Standard
| 3.7
| 2
|
modular steel structure
|
| Standard
| /
| 1
|
feeding conveyor
| Specification
| B1000*6m
| 7.5
| 1
|
drive mode
| electric drum drive
| /
| 1
|
main conveyor
| Specification
| B1000 * 8.7m
| 7.5
| 1
|
drive mode
| electric drum drive
| /
| 1
|
underscreen conveyor
| Specification
| B1200*6.2m
| 7.5
| 1
|
drive mode
| electric drum drive
| /
| 1
|
transfer conveyor
| Specification
| B650*2m
| 3
| 1
|
drive mode
| electric drum drive
| /
| 1
|
return conveyor
| Specification
| B500*9.5m
| 5.5
| 1
|
drive mode
| electric drum drive
| /
| 1
|
Electrical System
| Electric control cabinet
| Host soft start, electrical components Chint
| /
| 1 set
|
| Belt conveyor folding cylinder
|
| /
| 1 set
|
Hydraulic Pumps, Valves, Stations and Tubing Accessories
|
| /
| 1 set
|
Total power 288.4KW
|
Special Design of different models of the mobile crushing plant will be available upon request.
PRODUCT EXHIBITION
PRODUCT ADVANTAGES
Excellent grain shape
The material is crushed by the principle of lamination crushing, with high crushing efficiency and low wear of wearing parts. After crushing, the finished product is cubic with high fine-grained content, which can well meet the needs of some high-quality aggregates at this stage.
Wider applicability
This series of cone crushers has a larger feeding port, which can exert maximum performance to adapt to various crushing processes. It is widely used in medium crushing, ultra-fine crushing, stationary and mobile crushing plants. The optimized design of crushing speed, eccentricity (stroke) and cavity design are perfectly combined to provide higher capacity and better product quality.
High degree of automation
The thin oil lubrication system adopts the redundant design of double oil pumps and double filters, which can be lubricated before the equipment is started, with strong adaptability, easy control, and prolongs the service life of parts.
Integrated motor installation
The integrated installation method of the motor base and the crusher frame not only saves the installation space of the jaw crusher.
Moreover, due to the synchronous movement of the frame, the motor base and the motor, and the adjustable motor base, the tension of the V-belt can be adjusted so that the service life of the V-belt is longer.
PRODUCT APPLICATION
Processed Material:Limestone, Granite, Basalt, River Stone, Quartz, Copper Ore, Iron Ore, Marble.etc
CUSTOMERS' SITES
Packaging and Shipping
view more >>Recommended by seller
Quarry Cone Crusher Symons Cone Crusher For Rock Stone Crushing$34,000.00 / set1 set
High Efficiency Crushing Plant Mobile Stone Concrete Jaw Crusher Price$25,000.00 - $74,000.00 / set1.0 set
50-100tph Capacity Mobile Stone Crusher Aggregate Rock Crushing Plant For Sale$119,600.00 / set1 set
About VANGUARD
Zhengzhou Vanguard Machinery Technology Co., Ltd. is a professional high-end equipment manufacturing enterprise integrating R&D, production and sales. Its business scope covers sand and gravel aggregates, industrial grinding powder, mobile crushing plant, mineral processing machine, EPC general contract project, etc. Our factory covers 110000 square meters and our products are sold to more than 100 countries, being the popular manufacturer in global mining industry.
Matching of production and support system allows customers to get the best service at the lowest cost.
Qualification
All of our products have passed ISO9001-2008 international quality management system certification, European CE certification and Russia GOST certification, and our company has established a fully controlled quality management system. We are playing a leading role in quarry mining, sand making and industry powder producing fields.
Our Services
FAQ
Q1: what will you do if the machine is broken down? Does your company supply the spare parts?
A: The Products warranty is 12 months. We will provide the technical advice and find the solution immediately for you when the machine is in trouble. And we will supply the spare parts with high quality for you at lowest cost.
Q2: How long is your delivery time？
A: The lead time is 10-30 days. Delivery time will vary depending on the type of the machine, availability and shipping method.
Q3：What is the shape of the aggregate made by your company's crusher?
A: The shape of the aggregate is related to the design of the crusher or the complete stone production line. Our engineers will
design the most suitable proposal based on raw materials.
Q4: How about the quality of your equipment?
A: Our products are manufactured strictly according to national and international standard, and we will take a test on every set of machine before delivery.
>>
