W117 10.1 inch 8GB RAM 4G LTE SIM Card Rugged Tablet Windows 11 with Ethernet Port 1) 10.1 Inch 700cd/m2 High Brightness Screen 2) IP65/MIL-STD-810G Waterproof
| BASIC INFO |
| Model No. | WinPad W117 |
| Operating System | Windows 11 Pro (Win 10 home/ iOT optional) |
| Dimension | 274.9*188.7*23.1mm |
| Weight | 1140g (include battery) |
| Color | Black |
| Language | Multi-language |
| HARDWARE |
| Screen | 10.1 inch 7H hardness glass IPS capacitive screen, 1280*800px, 700cd/m2 |
| Processor | Intel JASPER LAKE N5100 quad core, 2.8GHz; GPU: Intel HD Graphics Gen 11 LP |
| RAM | 8GB LPDDR3 |
| ROM | 128GB EMMC, support Micro SD card up to 512GB maximally |
| Camera | Double cameras: 5.0MP front, 8.0MP AF rear camera with flashlight |
| Battery | Built-in 3V/1mAh battery+ removable 7.6V/5000mAh Li-Polymer battery |
| G-sensor | Support |
| Speaker | Embedded 8Ω/1W speaker*2 |
| LED Indicator | RGB |
| Mic | Single MIC |
| Keys | Custom button*1, Power key*1, Volume key+/-*1, Home key*1 |
| NETWORK & CONNECTIVITY |
| Network Bands | 2G GSM900/1800MHz |
| 3G WCDMA850/900/2100MHz |
| 4G FDD-LTE B1/B3/B5/B7/B8/B20, TDD-LTE: B40 (American Bands Module Optional) |
| WiFi | IEEE 802.11a/b/g/n/ac, support 2.4G/5.8GHz dual band WiFi |
| BT | V4.2(BLE), transmission distance: up to 10 meters |
| GNSS | Support GPS/A-GPS/Beidou/GLONASS |
| I/O INTERFACES |
| Micro SD slot | *1 |
| Nano SIM slot | *1 |
| USB Type-A 3.0 | *1 |
| USB Type-C 2.0 | *1 |
| 3.5mm Audio Jack | *1 |
| Mini HD-MI 1.4a | *1 |
| 12pin Pogo Pin | *1 |
| OPTIONAL FUNCTIONS |
| 2D barcode scanning | Optional (Honeywell N3680) |
| NFC | Optional (Support 14443A/14443B/15693/18092/mifare protocol) |
| RJ45/DB9/USB-A 2.0 | Optional |
| RELIABILITY |
| Waterproof | IP65/MIL-STD-810G |
| Drop-proof | 1.22m drop |
| Electrostatic discharge | ± 8KV contact discharge, ± 10kV air discharge |
| Temperature range | Operating: '-20 °C to 60 °C, storage: '-30 °C to 70 °C |
| Humidity range | 95% Non-Condensing |
| STANDARD ACCESSORIES |
| Power Adaptor (19V/3.42A) | *1 |
| Hand Strap | *1 |
| USB cable | *1 |
| Charging Dock | Optional |
| Car Charger | Optional |
| Shoulder Strap | Optional |
