15% Discount High Performance Compound Cone Crusher with CE

Product Description

15% Discount high performance Compound Cone Crusher with CE
The Compound Cone Crusher is the cone crusher which is the earliest appearance in the world, and it is used widest and larger quantity crush mechanism in present. With the improvement of the series of Compound Cone Crusher, their structure is more perfect and the technology parameter is more advanced, so these crushers have excellent performance in the aspects of manufacture, installation, use and maintenance etc.
Compound Cone Crusher Main Features:
1. Many cavity types to meet customer's different requirements.
2. Credible dry oil seal prolongs the cycle of the lube and use life.
3. Special material used in key assemblies to support large crush power.
4. High productivity and efficiency.
5. Low cost of daily run and maintenance.
Compound Cone Crusher technical data:

Model	Movable Cone Diametermm (inch)	Chamber Style	Opening Side	Closed Side	Discharging Opening (mm)	REV (r/min)	Power (kw)	Motor Model	Capacity (t/h)	Machine Size (mm)
			Max.Feeding (mm)
36(3′)	900 (3′)	medium	83	102	9-22	580	6-75	Y315S-6/75	45-91	2821×1880 ×2164
		coarse	159	175	13-38				59-163
36(3′)	914 (3′)	fine	13	41	3-13	580	6-75	Y315S-6/75	27-90	2821×1880 ×2410
		medium	33	60	3-16				27-100
		coarse	51	76	6-19				65-140
51(4.25′)	1295 (4 1/4′)	fine	109	137	13-31	485	6-185	Y355M2-6/185	109-181	2800×2342 ×2668
		medium	188	210	16-31				132-253
		coarse	216	241	19-51				172-349
51(4.25′)	1295 (4 1/4′)	fine	29	64	3-16	485	6-160	Y355M1-6/160	36-163	2800×2342 ×2668
		medium	54	89	6-16				82-163
		coarse	70	105	10-25				109-227
66(5.5′)	1650 (5 1/2′)	fine	188	209	16-38	485	6-240		181-327	3911×2870 ×3771
		medium	213	241	22-51				258-417
		coarse	241	268	25-64				299-635
66(5.5′)	1650 (5 1/2′)	fine	35	70	5-13	485	6-240		90-209	3917×2870 ×3771
		medium	54	89	6-19				136-281
		coarse	98	133	10-25				190-336
84(7′)	2134 (7′)	fine	253	278	19-38	435	6-400		381-726	5200×4300 ×4700
		medium	303	334	25-51				608-998
		coarse	334	369	31-64				870-1400
84(7′)	2134 (7′)	fine	51	105	5-16	435	6-400		190-408	5200×4300 ×4700
		medium	95	133	10-19				354-508
		coarse	127	178	13-25				454-599

---
