Model
| MJ-SC-KL24
| MJ-SC-KL19A
| MJ-SC-KL19
| MJ-SC-KL1
|
measuring range
| 0.01%~40%
| 0.01%~40%
| 0.01%~40%
| 0.01%~40%
|
Test method
| Coulometric titration
| Coulometric titration
| Coulometric titration
| Coulometric titration
|
Resolution of sulfur measurement
| 0.001%
| 0.001%
| 0.001%
| 0.001%
|
Working furnace temperature
| 1150 ℃(coal, coke), 900 ℃(oil), ±2℃
| 1150 ℃(coal, coke), 900 ℃(oil), ±2℃
| 1150 ℃(coal, coke), 900 ℃(oil), ±2℃
| 1150 ℃(coal, coke), 900 ℃(oil), ±2℃
|
Sample mass
| 50± 10mg (coal, coke); 100 ± 10mg (petroleum products)
| 50± 10mg (coal, coke); 100 ± 10mg (petroleum products)
| 50± 10mg (coal, coke); 100 ± 10mg (petroleum products)
| 50± 10mg (coal, coke); 100 ± 10mg (petroleum products)
|
Sample delivery
| Automatic sample weighing, feeding
| Automatic sample feeding, discarding
| Automatic sample feeding, discarding
| Automatic sample feeding
|
MCPC module
| √
| √
| /
| /
|
Touch screen
| √
| √
| /
| /
|
Built-in balance
| √
| /
| /
| /
|
Number of samples
| 24
| 19
| 19
| 1
|
Single sample analysis time
| About 4min
| About 4min
| About 4min
| About 4min
|
Power
| ≤3KW
| ≤3KW
| ≤3KW
| ≤3KW
|
Working power supply
| AC220V±22V/50H
| AC220V±22V/50H
| AC220V±22V/50H
| AC220V±22V/50H
|
Overall dimensions
| 640×570×820(mm)
| 1010×500×380(mm)
| 1010×500×380(mm)
| 620×500×380(mm)
|
Net weight
| 94kg
| 81kg
| 78kg
| 51kg
|
