Basic Info.
Application
Hole Drilling Machines,etc
Detection Object
Iron 12X12X1mm
Response Frequency
DC:0.5kHz, AC:25Hz
Transport Package
1PCS/Bag
Packaging & Delivery
Package Size
8.00cm * 6.00cm * 6.00cm
Package Gross Weight
0.150kg
Product Description
LM12 Inductive Proximity Sensor Switch
The LM series inductive proximity sensors feature solid sensing performance, excellent noise immunity and protection circuits. Available in various sizes and sensing distances, the standard cylindrical inductive sensors can be used in diverse applications requiring non-contact detection of metallic objects. Main features IP67 protection structure (IEC standard) Operation indicator (red LED) PTFE coating prevents malfunctions caused by welding spatter (spatter-resistant models) Available in Various Sizes and Cable Types The sensors are available in M8, M12, M18, M30 size models, and cable/cable connector/connector types allowing installation in tight or limited spaces and various other user settings.
Applications
Graphic panels, fiber optic sensors, and proximity sensors are used on hole drilling machines.
Technical data:
| Structural category | Cylinder type |
| Outward appearance code | LM12 |
| Flush | Detection distance | 2mm |
DC 6~ 36 VDC | NPN | NO | LM12-3002NA |
| NC | LM12-3002NB |
| NO+NC | LM12-3002NC |
| PNP | NO | LM12-3002PA |
| NC | LM12-3002PB |
| NO+NC | LM12-3002PC |
| Two wire system | NO | LM12-3002LA |
| NC | LM12-3002LB |
AC 90~ 250 VAC | SCR controllable silicon | NO | LM12-2002A |
| NC | LM12-2002B |
| NO+NC | |
| Relay output | |
| Non-flush | Detection distance | 4mm |
DC 6~ 36 VDC | NPN | NO | LM12-3004NA |
| NC | LM12-3004NB |
| NO+NC | LM12-3004NC |
| PNP | NO | LM12-3004PA |
| NC | LM12-3004PB |
| NO+NC | LM12-3004PC |
| Two wire system | NO | LM12-3004LA |
| NC | LM12-3004LB |
AC 90~ 250 VAC | SCR | NO | LM12-2004A |
| NC | LM12-2004B |
| NO+NC | |
| Relay output | |
| | DC | 200mA |
| SCR/Relay | 300mA |
| Output voltage dropDC/AC | DC< 3V, AC< 10V |
| Consumption current | DC< 15mA, AC< 10mA |
| Standard detected object | 15× 15× 1(A3 ) |
| Repeated precision | 0.01 |
| DC/AC Response frequency | 400Hz/25Hz |
| Working environment temperature | -25 ~+75 |
| Insulation resistance | ≥ 50MΩ |
| Shell material | Metal |
| Protection grade | IP67 |
| Altemative model at home and abroad | E2E-X5M |
>>
