| model | D266 |
| navar | system | FANUC | The new generation |
| Fast moving speed | X-axis 24m / min other axis 30m / min |
| range of work | Holding rod material diameter of main and secondary shaft | φ5-φ26mm |
| Maximum drilling diameter of the main and secondary shaft | φ10mm |
| Maximum tapping tooth diameter of the main and secondary axis | M8 |
| Maximum drilling diameter of the secondary spindle | φ8mm |
| Maximum tapping tooth diameter of the secondary spindle | M6 |
| Electric spindle | Maximum drilling diameter of the side milling power head | φ10mm |
| Side milling power head maximum tapping tooth diameter | M8 |
| fast headstock | Power of main and sub-axes | 5.5KW | 8.2KW |
| Maximum rotation speed of the main and secondary shaft | 8000r/min |
| Maximum mobility | Sink-type activity guide set itinerary | 220mm |
| No guide (optional) | 360mm |
| cutter | Number of knives | 7 put 16x16mm |
| Side power tool | 5 with an ER20 power cutter |
| Maximum rotation speed of the power head | 5500r/min |
| Spindle end tool | 4 ER16 fixed tools plus 3 ER20 power tools |
| Secondary spindle end face cutting tool | 5 ER16 fixed tools plus 8 ER16 power tools |
| Machine tool appearance | Size (length, width and height) | 2700x1450x1800mm |
| Machine tool weight | weight | 3700kg |
