40m3/H Concrete Conveyor Trailer Pumps Hbts40 Professional Manufacturer

Product Description

40M3/H Concrete Conveyor Trailer Pumps HBTS40 Professional Manufacturer
Portable Diesel Trailer Concrete Pump, Diesel Concrete Pump:
HBTS20 20m3/h, HBTS30 30m3/h, HBTS40 40m3/h,HBTS60 60m3/h, HBTS80 80m3/h
Description of FOCUS portable diesel trailer concrete pump|diesel trailer pump|diesel concrete pump
FOCUS trailer concrete pump is categorized into two types of engine powered: Electric motor and diesel engine, also called trailer concrete pump, trailer pump, mortar pump, trailer mortar pump, diesel pump, diesel concrete pump, diesel mortar pump, electric concrete pump, electric cement pump,
Parameter of Diesel trailer concrete pump:

Model Parameter	HBTSA40-10-66R	HBTSB40-10-66R	HBTSC40-12-82R
Main oil pump	Kawasaki, South Korea	Kawasaki, South Korea	Kawasaki, South Korea
Displacement of main oil pump (ml / r)	112	112	112
Theoretical displacement (cubic) high / low	40/27	40/30	40/33
Engine	Delil 66	Delil 66	Weichai Deutz 82
Bore / stroke of main oil cylinder (mm)	Φ100/1300	Φ100/1300	Φ100/1200
Concrete cylinder bore / stroke (mm)	Φ160/1300	Φ180/1300	Φ180/1200
Hydraulic hose	Italy Manuli	Italy Manuli	Italy Manuli
Seal	American Parker	American Parker	American Parker
Electronic control system	Schneider, France	Schneider, France	Schneider, France
PLC unit	Omron Japan	Omron Japan	Omron Japan
Remote control	Wireless remote control	Wireless remote control	Wireless remote control
Pumping distance horizontal / vertical (m)	600/180	600/180	600/180
Pressure gauge	Imported from Germany	Imported from Germany	Imported from Germany
Button	Schneider, France	Schneider, France	Schneider, France
Lubrication system	Fully automatic	Fully automatic	Fully automatic
Lubrication system	hydraulic	hydraulic	hydraulic
Outlet diameter (mm)	Φ125	Φ150	Φ150
Piping (m)	100Φ125	100Φ125	100Φ125

Model Parameter	HBTS40-13-45	HBTS40-13-55
Main oil pump	Kawasaki, South Korea	Kawasaki, South Korea
Displacement of main oil pump (ml / r)	112	112
Hourly workload (cubic)	40	40
Motor Power	45	55
Bore / stroke of main oil cylinder (mm)	Φ100/1100	Φ100/1100
Concrete cylinder bore / stroke (mm)	Φ160/1100	Φ160/1100
Hydraulic hose	Italy Manuli	Italy Manuli
Seal	American Parker	American Parker
Electronic control system	Schneider, France	Schneider, France
PLC unit	Omron Japan	Omron Japan
Remote control	Wireless remote control	Wireless remote control
Pressure gauge	Imported from Germany	Imported from Germany
Button	Schneider, France	Schneider, France
Lubrication system	Fully automatic hydraulic	Fully automatic hydraulic
Outlet diameter (mm)	Φ125	Φ125
Piping (m)	120Φ80 or 100Φ125	120Φ80 or 100Φ125

Main features of portable diesel trailer concrete pump|diesel trailer pump|diesel concrete pump are as follows:
1. Open hydraulic system with tri-pump and two circuit is adopted in the diesel trailer concrete pump, constant power control and pressure cut-off control can promise a multistage and reliable main pump.
2. High quality hydraulic components and valves use German REXROTH, the valve for switching high pressure to lower pressure is designed to be easily controlled, which can adjust the condition of the diesel trailer concrete pump easily in accordance with the requirement of job site.
3. The equipped leading overflow valve makes the overflow to be safer, the main pumping circuit and S valve circuit of the diesel trailer concrete pump are independent to each other, which makes the working system reliable and the changeover steady.

---
