| Processor System | |
| CPU | Intel Atom® C3558R 4C/4T 2.4GHz/17W |
| Memory | |
| Slot Number | 2 |
| Type | DDR4 UDIMM |
| Max Size | 256GB |
| Channels | Dual Channel |
| Storage | |
| SATA | 2 |
| MSATA | 1(colay CF card, default MSATA) |
| COM | |
| Port Number | 1×RJ45 COM，1×Header |
| Mode | RS232 |
| Expansion Slot | |
| Mini-PCIe | 1 |
| Mechanical & Environment | |
| Dimension | 204*236.5mm |
| PWR Input | Dual DC12V |
| Operation | 0~50℃，10%~90%RH，non-condensing |
| Storage | -25~75℃，5%~95%RH，non-condensing |
| IO & Connector | |
| Rear IO | 6×LAN（Intel I211AT） |
| 4×SFP(2*Gbe, 2*10Gbe） | |
| 2×USB2.0 | |
| 1×RJ45 COM | |
| 1×BYP_LED | |
| 1×JLED | |
| Internal Connector | 2×SATA，2×SATA_PWR，1×MSATA |
| 1×Mini-PCIe，2×PCIEx8 | |
| 1×JCPLD1，JCI1，1×JLPC1 | |
| 1×KB_MS，1×USB3.0，1×JUSB | |
| 1×JCOM，1×JGPIO | |
| 1×JBYP，1×LAN_LED，1×F_PANEL | |
| 2×SYS_FAN，1×CPU_FAN | |
| 1×DC_IN1，1×DC_IN2 | |
| 1×CLR_CMOS，1×JGUI1，1×JAT_ATX | |
