Waste Paper Recycle Used Egg Tray Machine

Product Description

Waste Paper Recycle Used Egg Tray Machine Product Description
HUATAO Egg Tray Machine Processing Equipment Introduction:
The pulp molding equipment we can provide can be divided into 800-1200 pieces per hour, 2000-3000 pieces per hour, 3000-4000 pieces per hour, 4000-6000 pieces per hour, and 7000 pieces per hour according to the output size. Various customer needs.
Advantages of our machines:
1. The roller drive and cold pressing of our molding machine are all controlled by a servo motor and a precision reducer to complete precise position control. This control method does not have the problem that the position of the drum cannot be precisely positioned due to mechanical wear. Thereby greatly improving the service life of the mold. And it is not easy to block the network, which improves the utilization rate of the machine.
2. Our machine adopts a split transmission design. That is, the three parts of transfer, roller, and cold pressing are completed by 3 servo motors. The three motors are organically connected through PLC and can be started individually or jointly. Not only is the start-up operation simple, but the transfer speed can be greatly improved due to the separate control of the transfer, which greatly improves the output of the single machine.
3. The machine has a high degree of automation and a high safety factor. Once the machine fails, the machine will automatically stop.
4. It is designed with a cold pressing mechanism. The machine is extruded by the cold die during the suction process, and the moisture in the product will be squeezed out, and it will be sucked away by the vacuum at the same time. Compared with the product produced by the machine without cold pressing, the water content is reduced by more than 6% - 8%. The load on the drying room is reduced and energy is saved. (The profit of the egg tray industry mainly depends on energy consumption. The smaller the energy consumption per unit of output, the greater the profit.)
5. The forming machine has a good function of brushing edges and molds. The product is neatly surrounded without burrs, and the time for brushing molds is reduced. Increased run time increases daily output.
Product Parameters

Model	Capacity(pcs/h)	Forming mold quantity	Total power(kw)	Materials consumption(kg/h)
HT-1*3	800-1000	3	34	23.8
HT-1*4	1000-1500	4	41.2	28.4
HT-3*4	2000	12	53.7	32.57
HT-4*4	2000-2500	16	57	39.9
HT-4*8	3000-4000	32	90	63
HT-5*8	5000-6000	40	150	105
HT-5*12	7000-8000	48	153	107.1

Detailed Photos
Processing:

---
