China Alva High-Speed Automatic Vacuum Adsorption Stacker/Woodworking Machine/Veneer Stacker Machine, Welcome to Purchase

Product Description

1.Product brief introduction
4/6/8 feet auto veneer vaccum palletizer automatic veneer stacker connects with log peeling machine, its function for automatically sorting wood veneer after peeling log, so it can save two labor cost and improve work efficiency.
High speed veneer stacker, can greatly reduce labor costs and improve production efficiency, we have a number of models for you to choose, such as, roller type, pressure plate type, and the most advanced adsorption type. The main size of the stakcer is 4ft and 8ft. And we can do other size as customer requirement as well.
The stacker is with high intelligent system which is controlled by PLC. It is able to match the speed of the peeling machine automatically with the support of several sensors fixed in different place to check on the veneer always. The unqualified products can be sorted out automatically according to the needs.It has functions like Automatic counting and alarming, automatic transferring.
2.Product parameter list

Model	ALVA-VS-4/8FT
use	Palletizing
Receiving speed	40-80m/min
Receiver Width	1300mm
Board length	2600mm
Received plate thickness	0.5-3mm
Board height	1200mm
Sorting level	Palletizing A/B
total power	30KW
Way of working	Pneumatic shot
Dimensions	10000*3300*2600mm
weight	4000KG

3.Product Advantage:
1) We always produce machinie according to our clients own conditions, make sure offer the most suitable machine to them.
2) This machine will sort and stack the good quality face wood veneer.
3) This machine can separate the waste and good quality wood veneer automatically.
4) Adapt to different veneer and plywood manufacture

4.Product picture
5.Main features
1) The veneer stacking machine is a great combination for the peeling machine. It greatly helps to improve the efficiency.
2) Driven by servo motor and precision screw feed.
3) Vacuum adsorption mode is more powerful to adsorb different thickness veneers no matter high thickness or low thickness.
4) The low quality veneer like big holes or not full piece will be sorted out automatically.


Why Choose Us:
lasering your logo on products and designing logo is free Inspect the machine before leaving the factory Oversea install and debug the equipment Train the first-line operator 24 hours online service Provide the VIDEO with install and debug the equipment Provide technical exchanging Delivery time within 30days No else charge MOQ≥1 Provide products quotation Provide Packaging customization service SupportWechat/Email/whatsapp/ We specializein this field for 25 years Excellent after-sale system Supporting visits to factory Company Profile

Alva corporate purpose
Create value for customers, create benefits for partners, create future for employees, and create wealth for society Quality Policy
Excellent quality, perfect service, continuous improvement, meeting customer requirements
Chairman of Alva's business philosophy:
To quote William Deming. Product quality is produced, not tested
Product quality is not shown in words, pictures, or videos, but is achieved step by step through continuous practice, innovation and reform. Every product of Alva is through technical research and development, production practice, and quality checks, and finally creates the most cost-effective products for our customers. Believe in China Alva, believe in your own choice. Alva never disappoints any client. thanks.

FAQ:

Q1:Can you customize products for clients?
A1: Yes, we can customize and produce crushing machinery according to customers' requirements or drawings.

Q2:What about your products quality?
A2:We can provide you samples for quality inspection. If you order, we guarantee the quality is same with sample. In case of quality problem, we can sign agreements and our company will perform the duties.

Q3:How can we trust your factory?
A3:We recommend that you come to our factory to see the goods,to verify the real situation of the products, and know more about our factory.

Q4:Why does the price often change?
A4:The price depends on the latest prices of the raw materials.

Q5:What about the contract signing?
A5: If you're satisfied with the products and our service, you can sign the contract with us, pay the deposit Then we'll produce the machines as soon as possible. If you are far away, we can sign the contract by fax. We will ensure the quality of the products and the accessories are complete.

Q6: How about delivery?
A: when the product is ready, it can be delivered to you after your full payment. Will provide technical guidance.

---
