US$2,400.00-3,200.00
|
1 Roll
(MOQ)
|
Basic Info.
Structure
Vertical Drilling Machine
Controlling Mode
Artificial
Precision
Normal Precision
Certification
CE, ISO 9001
Transport Package
Plywood Box
Specification
700*1150*2150mm
Production Capacity
350sets/Year
Product Description
Product Description
All main parts are made with quality cast iron.
Double speed motor, 12steps gear shift.
Unload tool device and coolant.
Strength spindle, large diameter column.
The model with A is electromagnetism cluth transmission feed, with B is mechanical feed.
Product Parameters
Item
| Vertial Drilling Machine
|
Model
| Z5035A
|
Max. drilling diameter
| 35mm
|
Max. tapping diameter
| M20
|
Distance from spindle axis to generating line of column
| 330mm
|
Distance from spindle nose to workable surface
| 610mm
|
Distance from spindle nose to base plate surface
| 1150mm
|
Spindle travel
| 150mm
|
Max. adjusment of workable and table rest
| 540mm
|
Swivel of table and table rest
| +/-45°
|
Spindle taper
| MT4
|
Range of spindle feeds
| 70-2600rpm
|
Number of spindle feeds
| 12
|
Spindle feed range
| 0.1,0.2,0.3mm/r
|
Column diameter
| 140mm
|
Effective working area of table (L*W)
| 424*424mm
|
Effective working area of base plate (L*W)
| 420*380mm
|
Dimension of T-slot of table and base plate
| 2-14mm, 2-16mm
|
Main motor power
| 1.5/2.2kw
|
Package size
| 700*1150*2150mm
|
Weight
| 670/730kg
|
Detailed Photos
Company Profile
Shandong Vedon Intelligent Equipment Co., Ltd. is a comprehensive industrial and trade enterprise in China who is specialized in metal cutting machinery and tools,coming with self import and export rights.Shandong Vedon Intelligent Equipment Co., Ltd. supply a wide range of products and service to its global customers, including vertical machining center, milling machine, radial drilling machine, vertical drilling machine, lathe, CNC lathe, HSS&TCT annular cutter, magnetic drill machine, band saw machine and non-sparking tools etc... They are widely sold to more than 50 countries and areas in Europe,America, and Aisa, relying on the reliable product quality, reasonable price and good after-sales service system.Shandong Vedon Intelligent Equipment Co., Ltd. follows the concept of credit management cooperation and win-win strategy, and it has good comments from society and clients.Here we sincerely hope to cooperate with you and create a bright future.
After Sales Service
Certifications
FAQ
Q1. Could I put my LOGO on it or paint my own color? A: Yes, As long as the order quantity reach to the MOQ.Q2. What's your trade terms? A: FOB, CIF, DAP or other terms are acceptable.Q3. Could I order trail small order? A: Yes,we have no MOQ for standard version products. The price is different from different order quantity.Q4. What points need to be confirmed before placing the order? A: Voltage, frequency, plug type trade term and have shipping agent or not.Q5. What is your terms of payment ? A: Payment≤1000USD, 100% in advance. Payment≥1000USD, 30% T/T in advance, 70% before shippment. If you have another question, pls feel free to contact us as below.
>>
