Basic Info.
Carrying Capacity
Weight Level
Feature
Explosion-Proof, Insulating
Certification
CE, ISO 9001
Manual Pump
Italy "Hydr-APP"
Color
Main Body Red+Safety Black&Orange
Material
Main Body:Q235B(Sgc400)+Soild Tyre
Transport Package
No Packing
Origin
Dongguan City, Guangdong Province, China
Production Capacity
100set/ Year
Product Description
Container Manual Mobile Yard Ramp for Loading/Unloading
Specification:
| Width | 2000mm |
| Total length | 11050mm |
| Capacity | 10ton |
| Adjust range | 1200~1700mm |
| Material | 32# "H" beam for main body, 14# "H" beam for bottom |
| Manual pump | Import from Italy, brand is " Oiltec" |
| Ramp weight | 3400kg |
| Warranty | 1 year for hydraulic system, 5 years for steel structure |
| Color | Optional |
| Tyre | Solid tyre |
| CE No. | DGS12082902 |
Description:
1, We have many years experience in designing and customize the container ramp as per customer's
requirement.
2, Operate manner: Manual.
3, The 32# "H" beam steel structure for side-frame main body and 14# "H" beam for under-frame make it much
stronger than the common steel tube structure.
4, Fixed lip structure suitable for any vehicle(including the 3-wheel forklift) to pass through.
5, 100% galvanized steel grating of the slope part, aim at rust protection and skid resistance.
6, Capacity: 10ton, 15ton. 20ton
7, Two solid tyres provide excellent traction without worry of puncture.
8, The end bracket can be connected with the forklift(we've drilled two hole on the fork of forklift, then put rod of
the bracket into the hole of the fork) and can be moved by the forklift in any direction. And the end bracket
also is galvanized.
9, Operated with manual(If you need, we also can make electric for you).
10, The tightening chain's design between truck and mobile loading ramp is easy for operation and safe.
11, Hydraulic retractable support leg is optional.
12, 1 year warranty for hydraulic system, 3 years warranty for steel structure.
13, Hydraulic retractable support leg is optional.
14, The demension for every part can be customized to suit to acture demand.
15, We also can make it with 3-side loading and unloading style.
Product pictures:
>>
