Mini Diesel Concrete Mixer Tdcm175

Product Description

Easily accessible engine cab and the cove can be removed to get good ventilation for cooling the engine,Four or two towing pneumatic wheel s are optional
Specifications:
Technical Specification

Model	TDCM175-6DB
Drum total volume (litres)	580
Unmixed capacity(litres)	280
Mixing capacity(litres)	175
Output per hour(m3)	4.5
Drum rolation(rpm)	21-25
Engine	Changfa R180BN diesel 5.67KW,Water cooling diesel manual start
Steel thickness of drum(mm)	4
Weight(kg)	650kg
Overall size(mm)	3720L*1160W*1860H
Container loading	24unit in 40HQ

Performance:
A rigged with advanced metallurgy and technology. Designed to perform for continuous
mass concreting toughness required at any site Machine
Chassis: Made from rectangular & square tubular sections of high strength
Drum:
Large drum with 20% overload capacity. Fabricated from rolled steel plates. Its bevel
shaped and revolves noiselessly on a single hot blasted ci gear. A quick homogeneous
mix with enhanced daily output is guaranteed
Hopper:
Top Covered ,Centrally Supported Hopper mounted on rectangular tube loaded arm ,
Specifically designed for rapid discharge
Operation Safety :
1 . Light, smooth and positive linkages allows operator fatigue working
2 . Full covered moving parts and dampeners provided in compliance with safety
regulations
3 . Ample space in the engine compartment facilitates air circulation and convenience in
maintenance.

---
