Titanium Grade 5 Plate Round Bar

US$15.00-20.00 500 kg (MOQ)

Basic Info.

Model NO.
30x210x440
Technique
Hot Rolled
Grade
GR5
Shape
Round
Name
Pipe
Product
Titanium Pipe
Transport Package
Standard Packing
Specification
length 400-6000mm, width 5mm-100mm, thickness 3mm
Trademark
titanium
Origin
Shanghai China
Production Capacity
500 Ton/Month

Product Description


Product Description
Good Quality Titanium Alloy Plate / round Bar
1. Products Introduction
Item Name Titanium foil / strip
Type GR1, GR2, GR3, GR4, GR5, 6AL4V Eli, GR7, GR9, GR12, GR23,TB3, TB6, TC4, TC6, TC11, TC17, TC18
Standard ASTM B265, AMS4911, AMS4911H, GB/T3621-2007
Specification 0.025-0.5mm Thickness 50-700mm width
Certificate ISO 9001:2008
Supply Ability 100 Tons per Month
Delivery Within 5~30 days


2. Chemical Composition
Grade N C H Fe O Al V Pa Mo Ni Ti
Gr1 0.03 0.08 0.015 0.2 0.18 / / / / / bal
Gr2 0.03 0.08 0.015 0.3 0.25 / / / / / bal
Gr3 0.05 0.08 0.015 0.3 0.35 / / / / / bal
Gr4 0.05 0.08 0.015 0.5 0.4 / / / / /
Gr5 0.05 0.08 0.015 0.4 0.2 5.5~6.75 3.5~4.5 / / / bal
Gr7 0.03 0.08 0.015 0.3 0.25 / / 0.12~0.25 / / bal
Gr9 0.03 0.08 0.015 0.25 0.15 2.5~3.5 2.0~3.0 / / / bal
Gr12 0.03 0.08 0.015 0.3 0.25 / / / 0.2~0.4 0.6~0.9 bal


3. Tensile Requirements
Grade Tensile strength(min) Yield Strength(min) Elongation(%)
ksi MPa ksi MPa
Gr1 35 240 20 138 24
Gr2 50 345 40 275 20
Gr3 65 450 55 380 18
Gr4 80 550 70 483 15
Gr5 130 895 120 828 10
Gr7 50 345 40 275 20
Gr9 90 620 70 438 15
Gr12 70 438 50 345 18

4. Contact us Shanghai Bozhong Metal Group Co., Ltd.
ADD: 5F, Building #32, No.518 Xinzhuan Rd, Songjiang District, Shanghai, P.R.China 201612
