| model | T10X50ED |
| magnification | 10X |
| Objective diameter (mm) | 50mm |
| Exit pupil diameter(mm) | 5mm |
| Body material | magnesium-aluminium alloy |
| Exit pupil distance(mm) | 19mm |
| objective | ED lens |
| prism | BAK4 |
| FOV | 6°12′ |
| FOV range | 108m/1000m |
| Focus distance | 2m |
| transmittance | 90% |
| Lens coating | FMC |
| Prism system | phase film+High Reflection Media film |
| waterproof | 1.5m/30mins |
| Gas filled | nitrogen |
| Weight (g) | 890 |
| dimension(cm) | 16.5X14X6 |
| accessories | Wide shoulder strap, waterproof soft bag, mirror cloth, certificate of conformity, colour box with instruction booklet |
