RosH compliance thermal gap pad with no silicone material for car battery & power supply
Z-Paster 140-20-11F Series is a high performance and compatible non-silicone material of the thermal conductive interface materials.The role is to fill the air gaps between the heating elements and the heat dissipation fins or the metal base.
It applies to the liner based on silicone suitably. The flexibility and elasticity make it suited to the coating of the very uneven surfaces.Heat can transmit to the metal housing or dissipation plate from the separate elements or even the entire PCB, which in effect enhances the efficiency and life-time of the heat-generating electronic components.
Features
Silicone-free
ROSH compliance
Good thermal conductive:2.0 W/mK
Soft and Compressible for low stress applications
Available in varies thickness
Application
Cooling components to the chassis of frame
Car Battery & Power Supply
Charging Pile
Silicone-sensitive applications
Graphics Card Thermal Module
Set Top Box
Medical devices
LED Lighting
SFP optical module
Miniature heat tube radiator
Typical Properties of Z-Paster140-20-11F
Product Name
Z-Paster140-20-11F
Colour
Dark grey
Construction & Compostion
Silicone-free The metal oxide fills
Thermal conductivity
2 W/mK
Hardness
60 Shore 00
Specific Gravity
2.65 g/cc
Thickness range
0.010"-0.200" (0.25mm-5.0mm)
Dielectric Breakdown Voltage (T= 1mm above)
>5000 VAC
Dielectric Constant
5.5 MHz
Volume Resistivity
6 X1013 Ohm-meter
Continuous Use Temp
– 20 To 125℃
Outgassing (TML)
0.30%
Flame Rating
94 V0
