CE Approved New Design Telescopic Boom Lift with 22m 24m 29m Lifting Height and Li-ion Battery Self-Propelled Cherry Picker/Manlift for Sale and Rent

Product Description

Product Parameters
TELESCOPIC BOOM LIFT
SPECIFICATION

Model	GTBZ22D	GTBZ24D	GTBZ29D
Working height maximum M	21.6	23.5	28.6
Platform height maximum M	19.6	21.5	26.6
Working radius maximum M	13.7	15.8	18.5
(L*W) Platform dimensions M	2.44*0.91	2.44*0.91	2.44*0.91
Lift capacity kg	300	300	300
Length (stowed) M	10.06	9.1	10.76
Width M	2.49	2.49	2.5
Height( stowed) M	2.6	2.59	2.83
Wheelbase M	2.5	2.5	3
Ground clearance M	0.35	0.35	0.35
Turning radius of inner wheel m	2.1	2.1	1.6
Turning radius of outer wheel m	5.4	5.4	4.73
Turntable rotation	360°	360°	360°
Platform rotation	±90°	±90°	±90°
Drive speed(stowed) km/h	4.4	4.4	4.4
Drive speed(raised) km/h	1.1	1.1	1.1
Max.Gradeability	40%	40%	40%
Solid tire specification	36×14-20	36×14-20	36×14-20
Battery V/Ah	48V460Ah(Lithium)	48V560Ah(Lithium)	48V300Ah(Lithium)
Charger V/A	48/60	48/60	48/60
Control voltaqe	12V	12V	12V
Drive Motor	4×4kW	4×4kW	4×4kW
Weight kg	9000	10000	12000
Platform Leveling	Automatic Leveling	Automatic Leveling	Automatic Leveling

STANDARD FUNCTION

1	Automatic Leveling Platform	15	Horn and buzzer safety warning
2	180°Hydraulic Rotary Platform	16	Strobe light
3	Driving confirmation	17	Maximum allowable 5 ° working inclination angle
4	Three handle gradient proportional control	18	Tilt protection system
5	Thumb rocker steering	19	High definition color large screen
6	Weighing system	20	Fault Diagnosis System
7	Foot switch	21	360 ° turntable rotation
8	Operator anti extrusion protection system	22	Turntable protection lock
9	Emergency stop system	23	Timer
10	Emergency descent system	24	Oil cylinder protective sleeve
11	Emergency braking release	25	Arm dustproof component
12	Descent and movement alarm	26	Front floating bridge
13	AC power cord connected to the platform	27	Four-wheel drive
14	Line protection sleeve	28	Four wheel brakes

INTRODUCTION
Can adapt to specific working environment, that is, can work in wet, corrosive, dusty, high temperature, low temperature environment.
The machine has the function of automatic walking, can be in different working conditions, fast and slow walking, only one person at the height of the operation can operate the machine to complete the lifting, forward, backward, steering, rotary and other actions, compared with the traditional hydraulic platform greatly improve the work efficiency, reduce the number of operators and labor intensity.
FEATURES JIB with a 90 °- 360 ° rotatable platform. The ability to drive and operate at full height Stabilization technology helps good performance Fast elevating boom at full height Unparalleled platform stabilization Smart control system make the lower energy consumption. Compact structure dimension for narrow space work. Straight boom provides greatest horizontal reach Best-in-class grade ability and reach Fastest lift and drive speeds for unmatched productivity

---
