FUJI Lift Panoramic Lift Passenger Lift with Cheap Price Glass Elevator Home Elevator Villa Lift Passenger Elevator Lift China Lift Manufacturer

Product Description

For passenger elevator Standard Decoration Optional(if you have other request,we can provide)

It's wall	Hairline stainless steel
Ceiling	LED Fluorescent, according to the car design
Car bottom	PVC
Jamb material	The first layer of hairline, the remaining steel plate Spraying
Hall door	The first layer of hairline, the remaining steel plate Spraying

Passenger Elevator Parameter

Load capacity (Kg)	Rated Speed m/s	Car Size cw*cd(mm)	Door Opening Size ew*eh(mm)	Shaft Size hw*hd(mm)	Top floor height Th(mm)	Pit Depth (mm)
450	1	1100×1100	800×2100	2050×1850	4500	1500
630	1	1400×1100	800×2100	2250×1900	4500	1500
	1.5				4700	1600
	1.75
800	1	1400×1350	800×2100	2200×1950	4000	1500
	1.5/ 1.75				4700	1600
1000	1	1500×1550	900×2100	2350×2150	4000	1600
	1.5/ 1.75				4700	1600
1600	1	1800*2000	1100*2100	2900*2200	4350	1500
	1.5/ 1.75				4500	1600

Small machine room or Machine roomless passenger elevator give you different options
Intellectial main control system
It gives first priority to effectiveness in vertical transport field.In order to fully optimize the service efficacy of the elevator system,FUJI elevator fulfills the intellectual managements such as multi-computer,modular and network control etc.Through fully computerized intellectual control system.It instantly feeds back the elevator running conditions.It provides the passengers with the most efficient gold-collar services.
New generation permanent magnet synchronous traction machine &Top advanced door operator system
Elevator Standard Functions

No.	Description name	Description	No.	Description name	Description
1	Static electricity protection	Eliminate static electricity raised from running of steps.	11	Over-load protection	Protection against risk of motor continually over-load.
2	Emergency stop button	Push the emergency stop button to shop the escalator/moving walk against emergency raise.	12	Step sagging protection	Protection against risk of steps being breakage and sagging.
3	Skirting protection	Protection against risk of foreign bodies being jammed into clearance between steps and skirting.	13	Broken step chain protection	Protection against risk of steps being breakage or under elongation.
4	Handrail entry safety protection	Protection against risk of foreign bodies being jammed into handrail entry.	14	Comb teeth safety protection	Protection against risk of foreign bodies being trapped at the point where the step enter the comb.
5	Main drive chains safety protection	Protection against risk of drive chains being breakage or undue elongation.	15	Handrail speed and broken handrail monitor	It detects the handrail speed and monitors the broken handrail.
6	Over-speed protection	Protection against risk of speed being over 20% of rated speed.	16	Skirting anti-clamp device	It sets protection brush in the skirting on both sides of the step.
7	Under-speed protection	Protection against risk of speed less than over 80% of rated speed.	17	Step missing detection	It detects the step missing in the stairway.
8	Un-intentional reversal protection	Protection against risk of unintentional reversal protection.	18	The brake opens the monitor switch	It monitors whether the brake opens or not in during the escalator running.
9	Floor-plate monitor switch	When the pit cover plate opens,it cuts off safety circuit and stops the escalator safety switch.	19	Handwheel and handwheel protection cover open safety	During the use of handwheel,when open the handwheel and the handwheel protection cover,the safety switch will cut the safety circuit against escalator running.
10	Short circuit protection	Protection against risk of short circuit.	20	Lack of phase,error phase protection	Protection against risk of phase failure.

---
