Wheel Hub Rough Forging for Articulated Dump Trucks

Product Description

Wheel Hub Rough Forging for Articulated Dump Trucks
Rough machined wheel hub forgings for articulated dump truck
Other products and materials:
1.Forged SHAFT,forged RING;forged BLOCK;forged FLANGE.
Pipe sheet,gear ring,slewing bearing ring...most of forging parts.
Forged steel flanges/carbon steel flanges/stainless steel flanges.
2.Material: 4130, 4140, 4317, 4142, 4340, UNS440, 34CrNi3Mo,25Cr2Ni4MOV,18CrNiMo5, 30CrMo, 9Cr2Mo, 9Cr2W, 9Cr3Mo, 60CrMoV etc.
3.Dual certified to ASME/ASTM SA/A182 and EN10222-5 or DIN17440
4.PED-AD 2000-Merkblatt W0

Forging Product Size Range
Forgings	Raw Material	Min.Size (mm)	Max.Size (mm)	Min.Weight (kgs)	Max.Weight (kgs)	Heat Treatment
Shaft	Carbon steel Stainless Steel Alloy Steel	Φ30×50	Φ800×5000	0.3	20000	Normalizing; Queching; Tempering Annealing; Quenching&High Temperature Tempering
Ring		Φ75 ×Φ15×12	Φ5000 ×Φ4500×300	0.3	9000
Disc		Φ90 ×20	Φ3500 ×100	0.5	10000
Block		100 ×100×100	1500 ×1500×1500	7.85	26000
Gear Ring		Φ75 ×Φ15×12	Φ5000 ×Φ4500×300	0.3	9000
Hollow Bar		Φ90 ×Φ49×133	Φ1000 ×Φ900×3000	4	12000
Other			Φ5000		30000

---
