1T intelligent computing powe,Supports deep algorithm learning to improve the performance of intelligent event algorithms Resolution up to 4MP(2688×1520),Output Full HD :2688×1520@30fps Live Image. Support H.265/H.264/MJPEG Video Compression Algorithm ,Multi-level Video Quality Configuration and Encoding Complexity Settings Starlight Low Illumination,0.0005Lux/F1.4(color),0.0001Lux/F1.4(B/W) ,0 Lux with IR 90X Optical Zoom,16X Digital Zoom Supports optical fog transmission, which greatly improves the foggy image effect Support 3-stream Technology, each stream can be independently configured with resolution and frame rate ICR automatic switching, 24 hours day and night monitoring Support Backlight Compensation, Automatic Electronic Shutter ,adapt to different monitoring environment Support 3D Digital Noise Reduction, High light Suppression, Electronic Image Stabilization, 120dB Optical Wide Dynamic Support 255 Preset,8 patrols Support Timed Capture and Event Capture Support One-click watch and One-click cruise functions Support 1 audio input and 1 audio output Built-in 1 alarm input and 1 alarm output, support alarm linkage function Support Micro SD / SDHC / SDXC card storage up to 256G ONVIF Rich interfaces for convenient function expansion Small size and low power consumption, easy to access PTZ
| Specifications |
| Camera | Image Sensor | 1/1.8" Progressive Scan CMOS |
| Minimum Illumination | Color:0.0005 Lux @(F2.1,AGC ON);B/W:0.00012.1Lux @(F2.1,AGC ON) |
| Shutter | 1/25s to 1/100,000s;Supports delayed shutter |
| Aperture | PIRIS |
| Day/Night Switch | IR cut filter |
| Digital zoom | 16X |
| Lens | Video Output | Network |
| Focal Length | 10.5-945mm,90X Optical Zoom |
| Aperture Range | F2.1-F11.2 |
| Horizontal Field of View | 38.4-0.46°(wide-tele) |
| Minimum Working Distance | 1m-10m (wide-tele) |
| Image(Maximum Resolution:2688*1520) | Zoom Speed | Approximately 8s(optical lens, wide-tele) |
| Main Stream | 50Hz: 25fps (2688*1520,1920 × 1080, 1280 × 960, 1280 × 720); 60Hz: 30fps (2688*1520,1920 × 1080, 1280 × 960, 1280 × 720) |
| Image Settings | Saturation, Brightness, Contrast and Sharpness can be adjusted via the client-side or browser |
| BLC | Support |
| Exposure Mode | AE / Aperture Priority / Shutter Priority / Manual Exposure |
| Focus Mode | Auto / One step / Manual/ Semi-Auto |
| Area Exposure / Focus | Support |
| Optical Defog | Support |
| Image Stabilization | Support |
| Day/Night Switch | Automatic, manual, timing, alarm trigger |
| 3D Noise Reduction | Support |
| Network | Storage Function | Support micro SD / SDHC / SDXC card (256g) offline local storage, NAS (NFS, SMB / CIFS support) |
| Protocols | TCP/IP,ICMP,HTTP,HTTPS,FTP,DHCP,DNS,RTP,RTSP,RTCP,NTP,SMTP,SNMP,IPv6 |
| Interface Protocol | ONVIF(PROFILE S,PROFILE G),GB28181-2016 |
| AI Algorithm | AI Computing Power | 1T |
| Interface | External Interface | 36pin FFC (Network port, RS485, RS232, CVBS,SDHC, Alarm In/Out
Line In/Out, power),LVDS |
| General | Working Temperature | -30ºC~60ºC, humidity≤95%(non-condensing) |
| Power supply | DC12V±25% |
| Power consumption | 2.5W MAX(I11.5W MAX) |
| Dimensions | 374*150*141.5mm |
| Weight | 5190g |
