IC698CHS117C GE Full series spare parts for gas turbine clamp module

Product Details

Product Description

Product Description
IC698CHS117C GE Full series spare parts for gas turbine clamp module
IC698CHS117C GE Full series spare parts for gas turbine clamp module
Our Email: 2235954483@qq.com
contact number:13313705507
contacts：HE
The GE Fanuc IC698CHS117 RX7i I/O Rack is made for the Rx7i PACsystem series. The IC698CHS117 Rack is a wall-mounted 18-slot I/O rack built for the VME64 backplane system and high-level power supply. This I/O rack has up to 4 times more bandwidth strength than the standard VME backplane systems and thus it provides faster I/O throughput. The IC698CHS117 Rack supports the GE Fanuc Rx7i CPUs, Rx7i I/O modules, Series 90-70 I/Os, and all the standard VME modules. It has a slot-sensing feature for rack-type I/O modules and it is configured with programming/configuration software, eliminating DIP switches and jumper configurations. All the Rx7i racks have an open-type design and they must use the IP 54 standard enclosures or enclosures with higher ratings for safe use in an industrial environment.
The IC698CHS117 Rack supports high-wattage Rx7i power supplies and Rx7i AC power supply plug-ins. It has a power supply rating of 350 Watts and current ratings of 4 Amps at -12 Volts, 12 Amps at 12 Volts DC, and 60 Amps at 5.0 Volts DC input. The IC698CHS117 Rack has 18 I/O slots that support up to 15 single-width I/O modules without any double-width modules, 8 double-width modules, or a combination of double-width and single-width modules. The IC698CHS117 module’s slots are numbered 1 through 18, with an average slot-width of 0.8 inches. Slot 1 is always reserved for the CPU. Double-width RX7i CPUs with embedded Ethernet cards use slots 1and 2. Slot 0 with a 2.6-inch slot-width is used for the power supply module. The IC698CHS117 Rack is configured by using the Windows-based and highly-intuitive CIMPLICITY Machine Edition Logic Developer-PLC software that provides a graphical interface for the users to configure the I/O addressing.

---
