| Feature: Closed-loop control and automatic check during charging, in order to keep battery in good state. After open, the charger automatic starts and work according to CHARCER applied charging curve. Small size,user- -friendly, simple maintenance, charging time8-12 hours. | |||||
| Model number | input voltage | Power | Size | battery capacity | Weight |
| GCAZXI-48V/40A | 3 Phase 380V | 3.OKVA | 460*410*500mm | 280-350AH | 45KG |
| GCAZXI-48V/45A | 3 Phase 380V | 3.4KVA | 460*410*500mm | 350-390AH | 50KG |
| GCAZXl-48V/50A | 3Phase380V | 3.8KVA | 460*410*500mm | 350-390AH | 5OKG |
| GCAZXlI-48V/60A | 3Phase380V | 4.5KVA | 460*410*500mm | 400-440AH | 55KG |
| GCAZXIl-48V/70A | 3Phase380V | 5.5KVA | 460*410*500mm | 480-550AH | 65KG |
| GCAZXIl-48V/80A | 3Phase380V | 6.OKVA | 540*490*600mm | 550-630AH | 65KG |
| GCAZXIl-48V/100A | 3Phase380V | 7.5KVA | 540*490*600mm | 630-700AH | 75KG |
| GCAZXIl-72V/60A | 3Phase380V | 6.8KVA | 460*410*500mm | 400-440AH | 68KG |
| GCAZXIl-72V/70A | 3 Phase 380V | 7.9KVA | 540*490*600mm | 480-550AH | 78KG |
| GCAZXIl-72V/80A | 3 Phase 380V | 9.OKVA | 540*490*600mm | 550-630AH | 85KG |
| GCAZXIl-80V/60A | 3 Phase 380V | 7.5KVA | 460*410*500mm | 400-440AH | 70KG |
| GCAZXIl-80V/70A | 3 Phase 380V | 8.8KVA | 540*490*600mm | 480-550AH | 80KG |
| GCAZXlI-80V/80A | 3 Phase 380V | 10.OKVA | 540*490*600mm | 550-630AH | 85KG |
| GCAZX II-80V/100A | 3 Phase 380V | 12.5KVA | 540*490*600mm | 630-700AH | 90KG |
