Best Quality China Wool Combing Machine, Wool Comber

Product Description

TECHNICAL FERTURES1 Speed:control by frequency:30~260cycles per minute
2 Lowest speed: 30 cycles per minute
3 Main motor:FB300: 3 kW-1500rpm Controlled by frequency inverter
4 Suction motor:1.1 kW-2800rpm
Feed creel motor: 0.25kW - 1400rpm
Delivery motor: 0.25kW - 1400rpm
Coiler motor: 0.40 kW - 1400rpm
5 Feed load in g/m:300~500;16~24slivers
6 Feed grid inside width:400 mm
7 Feed comb number :9
8 Feed length:4.5~8.8mm
9 Feed comb pinned length:410mm
10 Nipper working width:516 mm
11 Circular comb diameter:152 mm
12 Circular comb pinned width: 440 mm
13 Front comb pinned width: 470 mm
14 Drawing-off rollers diameter:25/28 mm
15 Circular brush diameter:160 mm
16 Circular brush width :430 mm
17 Clothed doffer diameter:138 mm
18 Drawing-off apron: Inside length 580×Width 540×Thickness3.5 mm
19 Feed creel type:Ball creel or Can creel Refer to the sales contract
20 Delivery type: Can delivery Refer to the sales contract for size
FB300 MACHINE PLANS Machine and delivery

Type	Size mm						Weight kg
	Φ	h	d	f	e	b	Machine	Delivery	Total
TC710J	700	1000	1832	392.5	683	1430	2650	255	2905
TC712J	700	1200	1832	392.5	683	1430	2650	300	2950
TC810J	800	1000	1832	392.5	683	1430	2650	255	2905
TC812J	800	1200	1832	392.5	683	1430	2650	300	2950
TC1012J	1000	1200	2037	607	783	1620	2650	505	3155

---
