US$99,999.00-299,999.00
|
1 Piece
(MOQ)
|
Basic Info.
Model NO.
BM30/50/1000/160
Making Method of Parison
Extrusion-Blow Molding
Computerized
Computerized
Certification
ISO9001:2008
After-sales Service
24-48h Response.on-Site Installation & Testing
Max Plasticizing Capacity (PE)
190PC/H
Main Screw Diameter
100mm
Transport Package
up to You
Production Capacity
180kg/H
Packaging & Delivery
Package Size
2500.00cm * 2000.00cm * 1500.00cm
Package Gross Weight
5000.000kg
Product Description
Product Parameters
| Model | Unit | BM30 | BM50 | BM100 | BM160 |
| Max product volume | L | 30 | 50 | 100 | 160 |
| Dry cycle | Pc/h | 600 | 450 | 360 | 300 |
| Die head structure | Accumulating type | Accumulating type | Accumulating type | Accumulating type | Accumulating type |
| Main screw diameter | mm | 80 | 90 | 100 | 100 |
| Max plasticizing capacity(PE) | kg/h | 120 | 180 | 190 | 240 |
| Driving motor | KW | 37 | 45 | 55 | 90 |
| Accumulating volume | L | 5.2 | 6.2 | 12.8 | 18 |
| Oil pump motor power | KW | 22 | 30 | 30 | 30 |
| Clamping force | KN | 280 | 400 | 600 | 800 |
| Space between platen | mm | 400-900 | 450-1200 | 500-1300 | 500-1400 |
| Platen size W*H | mm | 740*740 | 880*880 | 1020*1000 | 1120*1200 |
| Max.mould size | mm | 550*650 | 700*850 | 800*1200 | 900*1450 |
| Heating power of die head | KW | 20 | 28 | 30 | 30 |
| Machine dimension L*W*H | m | 4.3*2.2*3.5 | 5.6*2.4*3.8 | 5.5*2.5*4.0 | 7*3.5*4.0 |
| Machine weight | T | 12 | 13.5 | 16 | 20 |
| Total power | Kw | 95 | 110 | 135 | 172 |
Detailed Photos
Product Description
Product Description:
The JWZ-BM30/50/100/160 Blow Molding Machine is a high-performance, versatile solution specifically designed for the production of a wide range of automotive plastic parts, including urea boxes, toolboxes, air ducts, seats, flow boards, bumpers, and spoilers. This machine delivers superior precision, efficiency, and flexibility to meet the demands of modern automotive manufacturing.
Key Features:
Wide Application Range: Capable of producing multiple automotive components, such as urea boxes, toolboxes, air ducts, seats, flow boards, bumpers, and spoilers for both interior and exterior use. High-Output Extrusion System: Ensures efficient material usage and high production capacity. Accumulating Die Head: Guarantees consistent material distribution for durable and precise product results. Customizable Platen Design: Tailored to handle different product sizes and shapes, enhancing operational flexibility. JW-DB Hydraulic Screen-Exchanger System (Optional): Supports seamless material transitions, reducing waste and downtime. Hydraulic Servo Control System (Optional): Improves energy efficiency, precision, and operating speed. Optional Bottom Sealing and Take-Out Robot: Automates processes like sealing, product removal, and scrap management for cost-effective production. Applications:
Urea boxes for emissions control systems. Toolboxes and seats for practical automotive interiors. Air ducts, flow boards, bumpers, and spoilers for functional and aesthetic automotive needs. The JWZ-BM30/50/100/160 Blow Molding Machine is the ideal choice for manufacturers looking to produce a variety of automotive plastic components efficiently, with high precision and minimal material waste.
