Product Details
Product Description
Product Description
Servo motor series: low inertia, medium / high power. Rated output: 5.0kw.
Rated speed: 3000r / min. Electromagnetic brake: none.
Shaft end specification: Standard (straight shaft).
Features: low inertia, suitable for high-speed / high acceleration and
deceleration operation. IP rating: IP67. Application example:
1. Food processing machinery.
2. Printing press.
3. Injection molding machine (11kw, 15kw).
4. Large stamping machine (11kw, 15kw) hg-kr43j
The protection grade of hf-sp / hf-jp series servo motor is IP67 (except the
shaft through part).
Low inertia medium power servo motor (0.5KW ~ 9kw), large speed: 6000r / min
(rated speed: 3000r / min), suitable for high-frequency positioning and
acceleration / deceleration operations, especially food processing machines and
printing machines.
Low inertia high-power servo motor without cooling fan (11kw and 15kw), high
speed: 3000r / min (rated speed: 1500r / min). Due to the design of no cooling
fan, the motor structure is more compact, and the wiring is reduced by using
the power connector (compared with the hf-lp series servo motor with the same
power, the volume is reduced by about 46% and the weight is reduced by about
34%), which is suitable for high-frequency positioning and acceleration /
deceleration operations, especially injection molding machines and large
presses.
Hf-jp703 (4) / 903 (4) high speed: 5000r / min, servo motor series: flat type,
medium capacity. Rated output: 5.0kw.
Rated speed; 2000r/min。
Electromagnetic braking: attached. Power supply: 200V.
It is suitable for limiting the installation space in medium capacity and flat
products.
To improve the environmental resistance, hg-kr, hg-mr, hg-rr and hg-ur series
products adopt IP65. In 100 sites, there are 100 different drive controls. In
order to meet diversified and detailed site needs as much as possible,
In the configuration of mr-j4 product line, it provides rich servo amplifier
and servo motor products. It can meet the different needs of different
customers. Servo motor series: medium inertia, small capacity. Rated output:
0.5KW.
Rated speed: 2000r / min. Electromagnetic braking: attached. Power supply:
400V.
Realize the stable driving of medium capacity and medium inertia products.
Through the optimized structural design, the small total length in the industry
is realized.
High speed & high torque. Shorten positioning time and realize high-speed
equipment. Reduce power on torque ripple.
Through the combination of slot speed and torque, the smooth operation of the
motor can be further reduced.
To improve the environmental resistance, hg-sr and hg-jr series products adopt
IP67. Servo motor series: low inertia, medium power. Rated output: 0.5KW.
Rated speed: 2000r / min
Electromagnetic brake: with.
Shaft end specification: Standard (straight shaft).
Features: low inertia, widely used in general machinery. IP grade: IP65.
Application example:
1. Roller feed equipment.
2. Load / unload equipment.
3. High frequency transmission system.
The rich motor product line can optimize the performance of the machine.
It has a rich motor product line including rotary servo motor, linear servo
motor and direct drive motor.
>>
