| Brand Name | Tiancheng | | Style | VERTICAL |
| Condition | New | | Model NO. | TC-2200-2R |
| Screw Diameter (MM) | 42--45 | | Max.Hydaulic Pressure(Kg/cm3) | 140 |
| Maximum injection Pressure (Kg/cm2) | 2176--1742 | | Pump Output (L/min) | 76 |
| Theoretical Shot Volume (Cm3) | 318--365 | | Oil Tank Capacity (L) | 780 |
| Maximum Shot Weight (G/oz) | 325/11.4 | | Cooling Water Consumption(L/H) | 1000--1200 |
| Injection Rate (Cm3/sec) | 220--260 | | Electric Power (KW) | 30 |
| Screw Speed (R/Min) | 0--300 | | Total capacitance (KW) | 20.3 |
| Screw Rate (MM) | 240 | | Total Wattage (KW) | |
| Nozzle Retraction Stroke (MM) | 330 | | Machine Specification(M) | 3.2*2.55*4.1 |
| Clamping Force (Ton) | 220 | | Weight of Machine (KG) | 13000 |
| Opening Force (Ton) | 180 | | Plastic Processed | PP, ABS, FRPP/PVC, PE, ABS/PP, PE/PP |
| Platen Size (MM) | 1496 | | After-sales Service Provided
| Video technical support, Free spare parts, Field installation, commissioning and training, Field maintenance and repair service, Online support |
| Distance Between Tie-Bere (MM) | | | After Warranty Service
| Video technical support, Online support, Spare parts, Field maintenance and repair service |
| minimum Mold Thickness (MM) | 350/450 | | Warranty | 1 year |
| Opening Stroke (MM) | 350 | | Applicable Industries | Manufacturing Plant, Construction works , Energy & Mining, Other |
| Max-Distance opening mold (MM) | 700/800 | | | |
| Max.Mold Size | 600*550 | | | |
| Ejector Force (Ton) | 4.6 | | | |
| Ejector Stoke (MM) | | | | |
Q1: Are you a trading company or a manufacturer?
|
A1: Factory we are, all the machine are made by ourselves. Besides, you can get the customize service with your requirements
|
Q2: What's your warranty for the machine?
|
A2: One Year Warranty(all the machine parts can be replaced within one year free of charge, not including the manmade broke), life-time maintenance.
|
Q3: What's your Delivery Time?
|
A3: Usually it is 3-5 days if the machine is in stock; If not, the delivery time is 10-25 days according to your required quantity and our busy season.
|
Q4: Why choose TianCheng Machinery Co., Ltd.?
|
A4: "Tiancheng Machinery, we sincere, you succeed!" are the driving force for our company to moving forwards. We will devote every efforts to do the best level machine and service.
|
