Waterproof Outdoor Armoured Cable Assembly Pdlc-Dlc Fiber Optic Patch Cord

Product Description

Waterproof Outdoor Armoured Optical Cable Assembly PDLC-DLC patch cord 7.0mm, 2 Cores
PDLC Optical Cable Assembly Waterproof Outdoor Armoured Protected Cable is standard size for Duplex LC Connectors, and the outer housing with metal protective device. The connecting is safe and reliable. Also have the functions of waterproof, dust-proof. This patch cords widely used in FTTA, Base station, and the outdoor waterproof condition.
Features
The PDLC Waterproof Assembly is used for outdoor RRU transmitting optical signal and remote fiber feeder etc;
1. Standard Duplex LC connector, well connected with standard LC adapter
2. Available Single mode and Multi-mode
3. IP67 protection, salt-mist proof, humidity proof, dust proof
4. Low insertion/return loss, steady optical transmitting.
5. Light weight, waterproof, dust-proof, moisture proof, Metal hard housing.

Applications
1. Widely used in FTTA & FTTH
2. Used for 3G 4G base station
3. BBU, RRU, RRH, LTE


PDLC Waterproof outdoor fiber cable specifications

Item	Data
Insertion Loss	≤0.3dB
Mechanical life	500cycles
Working temperature	-40°C~+70°C
Storage temperature	-40°C~+70°C
Operating temperature	-10°C~+50°C
Protection Level	IP67
Tensile Data	Tensile between junction and fiber cable≥180N
Out shell inflaming retarding	UL94 V-0
Out shell Uvioresistant	UL 746C
Authentication	Meet with RoHS

1.1Cable Parameters

Fiber Count	Cable Dimension mm	Cable Weight kg/km	Tensile N		Crush N/100mm		Min. Bend Radius mm		Temperature
			Long Term	Short Term	Long Term	Short Term	Dynamic	Static
2	7.0	42.3	200	400	1100	2200	20D	10D	-30-+70
Note: 1. All the values in the table, which are for reference only, are subject to change without notice; 2. The cable dimension and weight are subject to the simplex cable of 2.0 outer diameter; 3. D is outer diameter of the round cable;

1.2 Cable Parameters

Fiber Count			2 Fibers
Fiber Type			SM G657A, or MM 50/125 or MM 62.5/125
Buffer	Diameter		900um±10um
	Material		LSZH
Simplex cable	Diameter		2.0mm±0.1mm
	Material		LSZH
	Color		SM: Blue and Yellow MM: Orange and Grey
Filler	Diameter		2.0mm±0.1mm
	Material		LSZH
	Color		Black
Strength Member			Kevlar
Jacket		Diameter	7.0±0.1mm
		Material	LSZH
		Color	Black

2. Connector Specification
2.1 Single mode

ITEM	PARAMETER
Connector type	LC/UPC, SC/UPC, FC/UPC, ST/UPC	LC/APC, SC/APC, FC/APC, ST/APC
Insertion Loss	<=0.2db	<=0.3db
Return Loss	>=50db	>=60db
Fiber mode	Single-mode
Operating wavelength	1310, 1550nm
Test wavelength	1310, 1550nm
Repeatability	<=0.1
Interchangeability	<=0.2dB
Durability	<=0.2dB
Fiber Length	1m, 2m….. other length optional
Length and tolerance	10cm
Operating Temperature	-40C ~ +85C
Storage Temperature	-40C ~ +85C

2.2 Multi mode

ITEM	PARAMETER
Connector type	LC/UPC, SC/UPC, FC/UPC, ST/UPC Optional
Fiber mode	Multi-mode
Operating wavelength	850, 1300nm
Test wavelength	850, 1300nm
Insertion Loss	<=0.2db
Return Loss	>=35db
Repeatability	<=0.1
Interchangeability	<=0.2dB
Durability	<=0.2dB
Fiber Length	1m, 2m….. other length optional.
Length and tolerance	10cm
Operating Temperature	-40C ~ +85C

Certificate
Our patch cord production line:
Shipping

Service:
1.Professional manufacturer, 100% tested.
2.Customers solutions in days, not weeks.
3.Warmly services with careful attentions.
4.Can provide your specific inquiry within 24 hours.
5.Save much costs, bring more benefit for customer to expand business.
6.We have been 9 years experience in this field. We are the prefessional supplier that you can trust.
FAQ
Q1:How can you guarantee the delivery time?

A:1. To avoid the delay, we have built a complete and professional procedure system from production to the deliver and have rich experience.
2. We can regulate the penalty clause in the contract for the late delay.

Q2:What's your best price?
A:Based on the quality of our products and the quantity of your estimated. We would quote the great best matching price all the time.

Q3:What's your MOQ?
A:Low MOQ, 1pc for sample checking is available

Q4:Can I print our own logo on the product?
A:Yes, Please send your logo to us.

Q5:Can you provide OEM/ODM service?
A:Yes, we can. Please tell us the details of your requirements
Q6: How to deal with the faulty?
A: Firstly, Our products are produced in strict quality control system and the defective rate will be less than 0.2%.
Secondly, during the guarantee period, we will send new with new order for small quantity. For defective batch products, we will repair them and resend them to you or we can discuss the solution including re-call according to real situation.
Q7:Why choose us to cooperate?
1. We have first-class production line and strict quality management system.
2. We have professional procedure system and big production capacity to guarantee fast deliver and on time shipment.
3. We can provide the most competitive price to meet your budget.
4. We also design and innovate the new products based on our rich experience .
5. We have professional team to provide comprehensive one-stop service for you.

Fiberlink Looks forwards to Long-Term&Win-Win business with customers.
We welcome your inquiry!!!

---
