| Input | 4/8/12 HD inputs for option | ||||
| 1 DVB-C Tuner input for remux, F type interface (only for DVB-C RF out) | |||||
| 128 IP input over UDP and RTP | |||||
| Video | Resolution | In-put | 1920×1080_60P, 1920×1080_60i, 1920×1080_50P, 1920×1080_50i, 1280×720_60P, 1280×720_50P, 720×576_50i,720×480_60i, | ||
| Out-put | 1920×1080_30P, 1920×1080_25P, 1280×720_30P, 1280×720_25P, 720×576_25P,720×480_30P, | ||||
| Encoding | MPEG-4 AVC/H.264 | ||||
| Bit Rate | 1Mbps~13Mbps each channel | ||||
| Rate Control | CBR/VBR | ||||
| GOP Structure | IP…P (P Frame adjustment, without B Frame ) | ||||
| Audio | Encoding | MPEG1 Layer 2; | |||
| Sampling rate | 48KHz | ||||
| Resolution | 24-bit | ||||
| Audio Gain | 0-255 Adjustable | ||||
| Bit-rate | 64kbps, 96kbps, 112kbps, 128kbps, 160kbps, 192kbps, 224kbps, 256kbps, 320kbps,384kbps | ||||
| Multiplexing | Maximum PID Remapping | 180 input per channel | |||
| Function | PID remapping ( automatically or manually) | ||||
| Accurate PCR adjusting | |||||
| Generate PSI/ SI table automatically | |||||
| Streaming | Maximum simulcrypt CA | 4 | |||
| Standard | EN300 429/ITU-T J.83A/B | ||||
| Connection | Local/remote connection | ||||
| Modulation | DVB-C | QAM Channel: 4 Standard: EN300 429/ITU-T J.83A/B MER: ≥40db RF frequency: 50~960MHz, 1KHz step RF output level: -26~-1dBm (81~106 dbµV), 0.1dBm Symbol Rate: 5.0Msps~7.0Msps, 1ksps stepping Constellation: 16/32/64/128/256QAM | |||
| J.83A | J.83B | ||||
| Constellation | 16/32/64/128/256QAM | 64/256 QAM | |||
| Bandwidth | 8M | 6M | |||
| DVB-T | Standard | EN300744 | |||
| FFT mode | 2K, | ||||
| Bandwidth | 6M, 7M, 8M | ||||
| Constellation | QPSK, 16QAM, 64QAM | ||||
| Guard Interval | 1/4, 1/8, 1/16, 1/32 | ||||
| FEC | 1/2, 2/3, 3/4, 5/6, 7/8 | ||||
| MER | ≥42 dB | ||||
| RF frequency | 50~960MHz, 1KHz step | ||||
| RF out | 4*RF COFDM DVB-T out (4 carriers combined output) | ||||
| RF output level | -28~ -3 dBm (77~97 dbµV), 0.1db step | ||||
| Stream output | RF output (F type interface) | ||||
| 4 IP MPTS output over UDP/RTP, 1*1000M Base-T Ethernet interface (Data1 only) | |||||
| System Function | Network management(WEB) | ||||
| Chinese and English language | |||||
| Ethernet software upgrade | |||||
| Miscellaneous | Dimension (W× L× H) | 482mm×410mm×44mm | |||
| Approx weight | 8kg | ||||
| Temperature | 0~45ºC(work), -20~80ºC(Storage) | ||||
| Power | AC 100V-220V±10%, 50/60Hz,AC 220 ±10%,50/60Hz | ||||
| Consumption | 70W | ||||
