Product Details
Product Description
Product Description
Lab small scale plant animal tissue high throughput tissue grinder grinding machine
High-throughput tissue grinder can grind 4× 96 pcs samples fast and efficient at the same time within 3 minutes. Can do dry grinding, wet grinding and mixing and homogenization.
Sample categories include: plant tissue (rice, corn, wheat, beans, peanuts,) animal tissues (muscle, intestine, heart, liver, lung, skin, bones, etc.), cells, bacteria, yeast and all kinds of herbs, etc.
To extract the nucleic acid from large high-throughput samples, greatly enhance the efficiency andquality of grinding. The labor cost is reduced and the labor intensity of the operator is lightened.
Principle
A small steel ball (or zirconia ball) is added to a grinding tank or centrifuge tube, and the grinding tank or adapter is
vertically vibrating. The ball is struck at high speed under high frequency vibration to grind the sample.
It adopts grinding ball to grind the sample, which make the grinding of the sample more uniform and sufficient than
the traditional grinding method.
Using high throughput tissue grinder, can be used as a homogenizer in grinding tank adding ball and cell beads broken the samples which it is difficult to crush by ultrasonic homogenizer, quickly dispersed samples with high density and small steel balls or zirconia beads.
Technical data
Model Number
| NB-48P Tissue Grinder
|
Product name
| 48holes High-Throughput Tissue Grinder
|
Application
| plant,animal tissue,cell,bacteria grind
|
Grinding method
| dry grind,wet grind,mixing and homogenization,liquid nitrogen grinding
|
Capacity
| 48*2ml,24*2ml,96*2ml
|
Adapter material
| Aluminium alloy,PTFE
|
Grinding kit material
| Stainless steel,PTFE
|
Grinding balls material
| Medical grade stainless steel, chrome steel, zirconia, tungsten carbide, quartz sand
|
Power
| 180W
|
Frequency Setting
| 10-70Hz,300-2100times/min
|
Clamp Stroke
| 34mm(vertical)
|
Display
| 7inch TFT Touch Screen
|
Noise
| | Dimension
| L369*W360*H520mm
|
Power supply
| 220V/50Hz
|
>>
