China Outdoor Duct Fiber Optic Cable Gyxts Single Mode 12 24 Core Optical Fiber Cable Manufacturer

US$0.13-0.58 2,000 Meters (MOQ)

Basic Info.

Model NO.

GYXTS

Connection Structure

Other

Material Shape

Round Wire

Allowed Lateral Pressure

100(N/100mm)<1000(N/100mm)

Allowed Tensile Strength

1000N<10000N

Core

2-24

Certification

RoHS, CE, ISO9001, VDE, CCC

Brand

Efon

Sheath Material

HDPE/Lszh Sheath/Flame Retardant Sheath/Anti-Roden

Fiber Type

G652D, Om1 Om2 Om3 Om4 9/125 50/125 62.5/125

Fiber Count

2-24

Fiber

Single Mode

Tube

Central Loose Tube

Armored

Corrugated Steel Tape/Aluminium Tape

Outer Sheath

PE/Lszh Sheath/Flame Retardant PE

Bend Radius

Static 10*Cable-D: Dynamic 20*Cable-D

Temperature

-40°c~+70°c

Certificate

ISO9001 TCL RoHS

Applications

Direct Burial, Tunnels and Heavy-Duty Ducts.

Transport Package

Wooden Drum Iron-Wooden Drum with Fumigated or Not

Specification

Trademark

OEM

Origin

China

HS Code

85447000

Production Capacity

300km/Week

Product Description

Outdoor Duct Fiber Optic Cable GYXTS Single Mode 12 24 Core Optical Fiber Cable Manufacturer
Product Description
Single-mode/multimode fibres are housed in a loose tube that is made of high-modulus plastic and filled with tube filling compound. The loose tube is armored with steel wires and corrugated steel tape. Then a PE outer sheath is extruded.
Features:
• Accurate process control ensuring good mechanical and temperature performances • The material of loose tubes with good hydrolysis resistance and relatively high strength• Tube filling compound providing key protection for fibres• Excellent crush resistance and flexibility• Wrapped steel wires providing good anti-rodent performance• Small size and light weight, easy for installation • Applicable to duct and aerial installations
Application:
External environments including LAN direct burial, tunnels and heavy-duty ducts. About Us
