V-Blender Cake and Powder Blender Mixer Dry Powder Mixer Drum Blender Mixing Machine for F

Product Description

3D movement mixer Product Description
The material is added to the mixing tank through the feeding machine or the vacuum feeding system. The mixing barrel space is crossed and perpendicular to each other. The main and driven shafts connected by the Y-type universal joint support the mixing barrel to make the threedimensional space. The unique translation, inversion and inversion movements accelerate the flow and diffusion during the mixing process, and avoid the segregation and accumulation of the specific gravity of the material caused by the centrifugal force of the general mixer, so that the material can be reached in a short time.
The machine is composed of machine base, drive system, three-dimensional motion mechanism, mixing cylinder, frequency conversion speed control motor, feeding outlet outlet, electrical control system, etc., the mixing cylinder in direct contact with the material is made of high-quality stainless steel material, and the inner wall of the cylinder is precision polished.

Features
• The mixing cylinder of the machine moves in multiple directions, the material has no centrifugal force, no specific gravity segregation and stratification, accumulation phenomenon, each component can have a disparity in weight ratio, the mixing rate is more than 99.9%, is a variety of mixers in an ideal product.
• The cylinder charging rate is large, up to 90% (ordinary mixer is only 40%), high efficiency and short mixing time.
Applications
This multi-directional motion mixer is a material mixer widely used in pharmaceutical , chemical , metallurgy , food , light industry , agriculture and other industries . The machine can mix powder or granules very evenly to achieve the best results after mixing .
Product Parameters

Model	SYH-5	SYH-20	SYH-50	SYH-100	SYH-200	SYH-400	SYH-600	SYH-800	SYH-1000	SYH-1500
Mixing Barrel Volume (L)	5	20	50	100	200	400	600	800	1000	1500
Mixing Loading Volume (L)	4	17	40	85	170	340	500	680	850	1270
Mixing Loading Weight (kg)	4	15	40	80	100	200	300	400	500	750
Spindle Rotation Speed (rpm)	3-20	3-20	3-20	3-15	3-15	3-15	3-10	3-10	3-10	3-8
Motor Power (kw)	0.37	0.55	1.1	1.5	2.2	4	5.5	7.5	7.5	711
Machine Weight (kg)	90	100	200	650	900	1350	1550	2500	2650	4500
