300ton Sanitary Fitting/ Bathroom Fitting / Sanitaryware Injection Molding Machine Stable Performance High Quality Competitive Cost Save Energy

US$1.00-47,240.00 1 Set (MOQ)

Basic Info.

Model NO.
ZX-300
Plastic Type
Thermoplastic
Plasticizing Way
Screw Type
Clamping Way
Hydraulic
Automation
Automatic
Computerized
Computerized
Certification
CE, ISO9001:2008
Motor Type
Servo Motor
Injection Weight
656-916g
Space Between Tie Bars
605 X 605 mm
Products
Sanitary, Bathroom Fitting, Sanitary Fitting
Transport Package
Plastic Film Cover, Wood Pad, Wrapped Film
Specification
6.4 x 1.6 x 2.4 M
Trademark
HANPLAS, OEM
Origin
China
HS Code
8477101090
Production Capacity
100PCS/Month

Product Description

300ton Sanitary Fitting Injection Molding Machine (Model: ZX-300)
1,Photo
2, Technical Parameter
ZX-300 Injection Unit Date A B C
Screw diameter mm 55 60 65
Screw L/D ratio / 22 20 18.5
Theoretical shot volume cm3 713 848 995
Shot weight(PS) g 656 780 916
Injection rate g/s 220 262 308
Max.screw speed rpm 195
Clamping Unit
Clamping force KN 3000
Toggle stroke mm 580
Space bettween tie bars mm 605x605
Min.mold thickness mm 220
Max.mold thickness mm 640
Hydraulic ejection stroke mm 180
Hydraulic ejection force KN 53
Others
Hydraulic system pressure Mpa 17.5
Pump motor kw 32
Heating capacity kw 17.2
Oil tank capacity L 450
Machine dimensions m 6.4x1.6x2.4
Machine weight Ton 8.5

3, Platen Dimension
4, Machine Dimension (ZX-300)
5, Technical Characteristics
7, Contact Information
Contact Person: Mr. Tony
Comapny: Ningbo Zhen Yue Machinery Co.,Ltd.
Address: No.39, Lane 158, Huangcheng West Road, Ningbo, China.
Zip Code: 315012
Mobile: +86 13656841356
Tel: +86 574 87082687
Website: zhenyuemachinery.en.made-in-china.com
Remark:
1, the company reserves the right to revise all information (including word, photo) above.
2, due to technology development, the machine design or specification would be changed without any prior notice.
3, if you need CE machine, please tell us in advance of order. Otherwise, we provide normal machine (not CE machine). CE machine is special and expensive.
