| ELECTRICAL SPECIFICATION | |||
| Nominal Voltage | 12.8V | ||
| Nominal Capacity | 50AH | ||
| Stored Energy | 640Wh | ||
| Resistance | 60 mΩ | ||
| Self Discharge Rate | Maximum Continous Charge Current | 50A | |
| Maximum Continous Discharge Current | 50A | ||
| Charge Cut-off Voltage | 15.6 V | ||
| Discharge Cut-off Voltage | 10V | ||
| Cycle life(25°C) | >4000 times@80%DOD | ||
| MECHANICAL SPECIFICATIONS | |
| Dimensions (mm) | L197×W166×H171 |
| Weight | 13.9lbs |
| Terminal Type | M6 |
| Case Material | ABS |
| Enclosure protection | IP64 |
| TEMPERATURE SPECIFICATIONS | |
| Discharge Temperature | 0 to 55°C |
| Charge Temperature | -10 to 55 °C |
| Storage Temperature | -20 to 60 °C |
| OTHERS SPECIFICATIONS | |
| Short Circuit Protection | Automatically recover after removal of short |
| Life Expectancy (years) | 10 years at one cycle per day |
