US$80,000.00-85,810.00
|
1 Piece
(MOQ)
|
Basic Info.
Transmission
Hydraulic Transmission
Drive Type
Internal Combustion Drive
Bucket Capacity
0.5~1.0m³
Certification
ISO9001: 2000, ISO14001
Hydraulic System
Kawasaki
Production Capacity
200 Units/Month
Product Description
Main Features
Unmatched performance driven by the Cummins Engine enhances torque output with more power and breakout force at lower engine speeds.
Options for auxiliary hydraulic piping include bidirectional variable high flow line, an additional line for rotating attachments and also a single acting line. The quick coupler further ensures you get the most out of your machine by easily switching between a wide range of attachments to suit any application.
Hydraulic request signals detect activity, decreasing and increasing engine speed as required. Power is supplied only as needed, achieving optimum fuel efficiency.
The lifting arm, arm and bucket of reinforced design offer for the complete unit a higher adaptability to severe working conditions, and implements such as breaking hammer and grab bucket can be installed as options.
The cab, spacious, bright, pantoscopic and properly sealed, is equipped with 8-way adjustable seat, two-stage filtering heater & A/C system and three-stage silicone oil rubber shock absorber, providing a good damping effect and a favorable driving comfort.
The upper structure is strongly reinforced by the use of an H-beam in the high cross section of the main structure providing even weight distribution and increasing stability.The platform's collision protection system has been welded into place to improve its strength, rigidity and overall service life.
Product Show
Specifications
| Engine | |
| Model | Cummins |
| Type | Six-cylinder,water-cooled, turbocharged,mechanical injection |
| Rated power | 112KW |
| Rated speed | 2100rpm |
| Main Technical Specification |
| Operating weight | 23000Kg |
| Standard bucket capacity | 1.0 m3 |
| Slewing speed | 12.5rpm |
| Stick digging force | 105KN |
| Bucket digging force | 152.5KN |
| Travelling System |
| Travelling speed | 0~5.7km/h |
| Grade ability | 70% |
| Ground pressure | 0.042MPa |
| Dimensions |
| Overall length | 9540mm |
| Overall width | 2990mm |
| Overall height of boom | 3040mm |
| Overall height of cab | 3040mm |
| Engine cover height | 2300mm |
| Counterweight clearance | 1070mm |
| Ground clearance | 440mm |
| Upperstructure width | 2740mm |
| Rear-end length/Slewing radius | 2750mm |
| Overall track length | 4160mm |
| Track length on ground | 3370mm |
| Track gauge | 2390mm |
| Track width | 600mm |
| Boom slewing angle(L/R) | 0 degree |
| Operating Scope |
| Arm length | 2915mm |
| Max. cutting height | 9945mm |
| Max. dumping height | 7170mm |
| Max. digging depth | 6562mm |
| Max. reach | 9870mm |
